(C102CS10) Glass Micro Cuvette, 10 mm Path, 1.75 mL

Weight	30 g

SKU: C102CS10

Original price was: $18.00.Current price is: $17.00.

In Stock

Glass micro cuvette for visible absorbance measurements with a 10 mm optical path, Two-Way Light layout and 1.75 mL nominal capacity. This version includes a PTFE lid and is sold as 1 cuvette per price unit.

In Stock

SKU: C102CS10 Categories: Cuvettes, Glass Cuvettes, Products Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C102CS10 is a glass micro cuvette for visible absorbance work when you want a standard 10 mm optical path in a smaller-capacity format. Its 1.75 mL nominal capacity and 5 mm sample region help you plan beam coverage and fill level more carefully than with a larger general-purpose cell. This sale unit includes 1 cuvette with a PTFE lid.

Path Length: 10 mm
Sample Volume (Nominal): 1.75 mL
Closure Type: Lid

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	Visible Absorbance Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Optical Window Dimensions	5 mm
Sample Volume (Nominal)	1.75 mL
Material	Glass
Closure Type	Lid
Closure Material	PTFE
Closure Included	Yes
Fabrication Method	Standard 80
Detection Channel Width	5 mm

Choose this option

Choose C102CS10 when your method is limited to visible-light measurements and you want a compact transmission cell rather than a UV-capable quartz version. The adhesive-bonded glass construction and visible-only use matter here because the sample and cleaning limits are narrower than for broader-range quartz cells.

What makes this option different

Visible absorbance use only, not a UV/Vis cuvette.
10 mm optical path with 1.75 mL nominal capacity in a micro cuvette format.
5 mm sample region for planning beam coverage in compact measurements.
PTFE lid included with this single-cuvette sale unit.

Using this cell

Fill the cuvette so the illuminated sample region is fully covered during measurement, and keep the optical faces clean and free from bubbles or residue. Use the same seating orientation for blank and sample runs to keep the transmission path consistent.

The 1.75 mL figure is the nominal capacity of the cell. It is not a minimum working volume, so lower-fill methods should be checked against the actual beam position in your instrument.

First-use check

Inspect the optical faces and lid for dust, chips or dried residue.
Test holder seating with the empty cell before filling.
Run a blank in the same orientation planned for samples.
Confirm that the liquid level fully covers the beam path without bubbles.

Fit and optical alignment

Match the instrument beam to the 5 mm sample region and check that the cell sits securely in your holder. Path length alone does not establish full instrument fit.

Z Height is not established for this SKU, and an externally verified body-size envelope is not available here for customer fit guidance. If your holder, clamp or compartment has limited clearance or depends on a fixed beam-center height, please check those points before ordering.

Solvents and cleaning

This adhesive-bonded Standard 80 construction is intended for routine visible-light work within the stated material limits. The lid should be considered as part of the full wetted assembly during use and cleaning.

Do not soak or rinse this cell with ethanol. It is not resistant to acids, alkalis or organic solvents under the supplier’s stated restriction for this adhesive construction. Use only mild compatible aqueous cleaning, avoid abrasive cleaning, and avoid aggressive chemical exposure during both sample handling and cleanup.

Included with this option

1 cuvette per listed price unit. Closure included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

For a modified design, we can review changes to dimensions, path length, capacity, optical windows, Z Height, closures or fabrication. Send your drawing, holder details, sample conditions and target quantity through this contact page and quote C102CS10.
