(C202CA7) Glass Standard Cuvette, 20 mm Path, 7 mL

Weight	100 g

SKU: C202CA7

Original price was: $27.00.Current price is: $25.00.

In Stock

C202CA7 is a glass standard cuvette with a 20 mm optical path, 7 mL nominal capacity and a supplied lid for covered top access during routine handling. Its specified 350–2000 nm range suits visible to near-infrared work, and the listed price is for a pack of four cuvettes.

In Stock

SKU: C202CA7 Categories: Cuvettes, Glass Cuvettes, Products Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C202CA7 is a glass standard cuvette for methods that use a 20 mm optical path and a covered sample opening. Its 7 mL nominal capacity gives a full-size sample chamber in a familiar rectangular body, while the supplied lid helps keep the top covered during handling between filling and measurement. The specified wavelength range is 350–2000 nm, so this option suits visible to near-infrared work rather than UV applications below 350 nm.

Path Length: 20 mm
Sample Volume (Nominal): 7 mL
Closure Type: Lid

Selection Specifications

Product Kind	Cuvette
Cell Type	Standard Cuvette
Measurement Mode	Absorbance Spectroscopy
Path Length	20 mm
Light Transmission Configuration	Two-Way Light
Wavelength Range — Lower Limit	350 nm
Wavelength Range — Upper Limit	2000 nm
Sample Volume (Nominal)	7 mL
External Dimensions	22.5 × 12.5 × 45 mm
Uncapped Cell Dimensions	22.5 × 12.5 × 45 mm
External Dimensions Scope	Uncapped Cell
Material	Glass
Closure Type	Lid
Closure Included	Yes

Choose this option

Choose C202CA7 when your method is set up for a 20 mm path and you want an open-fill cuvette supplied with a lid. That combination is useful when you need direct top access for pipetting and rinsing, but still want the sample opening covered during routine bench use. The nominal 7 mL capacity also makes this a practical choice for methods that are not built around micro-volume cells.

What makes this option different

Lid-covered top opening gives direct access for filling and cleaning, then covers the opening during normal handling; it is not presented as a pressure seal.
20 mm optical path suits methods written for this longer path length rather than standard 10 mm cells.
7 mL nominal capacity provides a full-size sample chamber; nominal volume is not the same as minimum working volume.
Fused integrated construction is the supplier’s stated build style for this cell, useful as a practical handling distinction when selecting a routine rigid cell body for repeated filling and rinsing, without implying a separate performance grade.
350–2000 nm specified range fits visible to near-infrared measurements and excludes UV work below 350 nm.
Pack of four cuvettes per listed price unit for this MQ offer.

Using this cell

Fill from the top so the liquid level fully covers the beam area used by your instrument, and keep the same orientation for blank and sample measurements. The lid is useful once the sample is in place, but this remains an open-fill cuvette rather than a leak-tested or pressure-rated assembly.

The 7 mL figure is a nominal capacity for the cell, not a minimum working fill. If your method depends on low fill height or a tightly defined beam position, check that your actual liquid level will cover the light path in your instrument.

First-use check

Inspect the optical faces for chips, scratches, dust or residue before first use. Confirm that the cell seats squarely in the holder, then run a blank after filling to make sure the beam is fully covered and no bubbles remain in the light path.

Fit and optical alignment

The recorded external size is 22.5 × 12.5 × 45 mm for the uncapped cell body. Use those uncapped dimensions when checking holder seating, and leave additional top clearance for the lid because the overall closed height is not specified here.

Z Height is not established for this SKU. If your holder or spectrometer requires a defined beam-center height, verify that separately before ordering rather than relying on the body size alone.

Solvents and cleaning

Use non-abrasive cleaning methods and handle the optical faces carefully. The supplier describes this type for acid/alkali use, but the exact chemical limits for this SKU are not established here, so check your sample liquid, concentration, temperature, contact time and cleaning routine before use, especially for aggressive reagents or mixed-solvent work.

For general background on cuvette construction approaches, see Compare fabrication options.

Included with this option

Price is for one pack of four C202CA7 cuvettes. A lid is included with this option.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

If you need a different path length, body size, sample volume or closure arrangement, we can review a custom version for your setup. Send your drawing or labelled sketch, holder or instrument details, sample conditions and required quantity through our contact page, and mention part number C202CA7.
