(MQQFL043) Short-Path Cuvette Holder, 12.5 × 12.5 mm Footprint

Weight50 g
SKU: MQQFL043

$132.00

In Stock

Separate short-path cuvette holder with a 12.5 × 12.5 mm outer footprint, 50 mm overall height and an open upright frame. The internal curved retaining strip supports a matching cell while the side openings leave the optical region accessible. One holder supplied; cuvette sold separately.

In Stock
Add to Wishlist
Add to Wishlist
Shipping and order support
  • Worldwide delivery to door service, hassle free shipping
  • Contact us for quotation of bulk purchase discount
  • Custom design. Send us graphic drawing for solution
  • POs for Academics. Pay after delivery.
  • Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

MQQFL043 is a separate holder for a compatible short-path cuvette. Its 12.5 × 12.5 mm outer footprint and 50 mm body height help turn a small or thin cell into a more practical assembly to handle during loading, positioning and removal. This item is a holder only, not an optical cell.

External Dimensions
12.5 × 12.5 × 50 mm
Pack Quantity
1 Piece

Selection Specifications

Product KindAccessory
External Dimensions12.5 × 12.5 × 50 mm
Body Height50 mm
Base Dimensions12.5 × 12.5 mm
Pack Quantity1 Piece
Package Contents1 × Cuvette holder

Choose this option

Choose MQQFL043 when your short-path cell is too small or thin to handle comfortably on its own and you need a holder with a standard square footprint. The holder gives you more body to grip while keeping the side opening accessible around the installed cell.

What makes this option different

  • Separate holder accessory, not a cuvette.
  • 12.5 × 12.5 mm outer footprint for matching square compartments.
  • 50 mm overall body height for easier insertion and removal.
  • Side openings leave the installed cell region accessible.
  • Internal curved retaining strip forms part of the cell-support area.

Structure and dimensions

Holder layout and cell-support openings.
Holder layout and cell-support openings.Open image ↗

Using this accessory

Insert the compatible short-path cell carefully into the holder and support the cell during handling. The holder provides a more convenient form to pick up and place, while the actual sample chamber and optical path remain those of the installed cuvette.

Use gentle handling when loading or removing the cell so that the holder guides the cuvette rather than forcing it into place. If you are working with a fragile or very thin cell, test the fit dry before routine use.

First-use check

Inspect the opening and contact surfaces for dust, chips or burrs, then test-fit the intended cell without sample. Make sure the cell sits naturally and can be removed again without strain.

Fit and optical alignment

Check both sides of the fit: the holder must suit your instrument compartment, and the installed cell must suit the holder opening. The 12.5 × 12.5 mm footprint and 50 mm height are the useful outer dimensions for compartment clearance.

The side opening matters because it leaves the cell region exposed rather than fully enclosed by the holder body. This helps with visual positioning and with beam access through the installed cell, but the holder itself does not define an optical path or instrument compatibility.

View the English selection reference.

English selection reference
Selection reference ↗

Handling and cleaning

Keep spills off the holder where possible and clean promptly with a gentle method that does not scratch the installed cell or leave residue on contact areas. Chemical limits for this accessory are not established here, so check your cleaning process against the actual holder and cuvette assembly you use.

Included with this option

1 cuvette holder.

Availability and ordering

Order this listed option directly, or contact us to check current availability and dispatch timing. For a required delivery date, please ask before checkout. Preparation time is separate from carrier transit and customs clearance.

Discuss a custom version

Need a different fit? Contact us with the mating cell and holder or instrument dimensions for review.
