(C104SS18) Quartz Micro Cuvette, 10 mm Path, 700 µL

Weight	30 g

SKU: C104SS18

Original price was: $132.00.Current price is: $119.00.

In Stock

C104SS18 is a quartz micro cuvette with a 10 mm path, Four-Way Light access and 700 µL nominal capacity. Its 2 mm sample-region width and included stopper suit compact UV/Vis and fluorescence setups that need optical access from more than one side. Supplied as 1 cuvette per price unit.

In Stock

SKU: C104SS18 Categories: Cuvettes, Products, Quartz Fluorescence Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C104SS18 is a quartz micro cuvette with a 10 mm optical path, Four-Way Light layout and 700 µL nominal capacity. It is a compact covered cell for UV/Vis and fluorescence work when you need access on multiple sides rather than a straight-through-only format. The included stopper keeps the sample chamber covered during filling, handling and measurement setup.

Path Length: 10 mm
Sample Volume (Nominal): 700 µL
Closure Type: Stopper

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	UV/Vis Spectroscopy; Fluorescence Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Four-Way Light
Optical Window Dimensions	2 mm
Sample Volume (Nominal)	700 µL
External Dimensions	12.5 × 12.5 × 45 mm
Uncapped Cell Dimensions	12.5 × 12.5 × 45 mm
Overall Height without Closure	45 mm
External Dimensions Scope	Uncapped Cell
Base Dimensions	12.5 × 12.5 mm
Material	Quartz
Closure Type	Stopper
Closure Included	Yes
Fabrication Method	Standard 80
Detection Channel Width	2 mm

Choose this option

Choose C104SS18 when you want a 10 mm micro cuvette but also need Four-Way Light access for a supported multi-side optical layout. The 700 µL nominal capacity keeps the body compact, and the 2 mm sample-region width is useful to consider when your beam footprint is relatively narrow. This is a practical choice when you want a covered quartz cell for UV/Vis or fluorescence work without moving to a larger cuvette format.

What makes this option different

Four-Way Light configuration: optical access on multiple sides of the cuvette body.
10 mm path in a micro format: standard path length in a compact covered cell.
700 µL nominal capacity with 2 mm sample-region width: useful for small-volume methods and beam-coverage planning.
Stopper included: supplied as 1 cuvette per price unit.

Using this cell

Fill the cell so the intended illuminated region is fully covered, and keep the optical faces free from bubbles, droplets and dried residue. For repeatable measurements, seat the cuvette the same way for blank and sample runs so the beam passes through the same orientation each time.

The nominal capacity is 700 µL, not a minimum working volume. If your method uses less than the nominal fill, verify in your own setup that the sample level still covers the beam position you plan to use.

First-use check

Inspect the optical faces on arrival, rinse the cuvette with a method-compatible liquid, and check that the stopper seats cleanly. A blank run is a useful first check for orientation, beam coverage and visible contamination in the optical region.

Fit and optical alignment

The uncapped body dimensions are 12.5 × 12.5 × 45 mm with a 12.5 × 12.5 mm base. These dimensions help you check holder seating and general clearance, but they do not define the overall height with the stopper fitted.

Z Height is not established for this SKU. If your instrument uses a fixed beam height or a holder with limited vertical tolerance, check that fit before ordering.

Because this is a Four-Way Light cell, selection should follow your actual beam geometry rather than assuming fit with any specific instrument model.

Solvents and cleaning

This SKU uses adhesive-bonded construction and is listed under Standard 80. This construction is best suited to routine water-based samples and buffers at room temperature. Avoid organic sample solvents and organic cleaning agents for this version.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the outer optical faces gently with non-abrasive optical tissue.

Included with this option

One cuvette is supplied per sale pack. The selected sale option states that a stopper and box are included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz cuvette projects for changes to dimensions, path length, sample volume, optical layout, closures and other fit requirements. Send a dimensioned drawing or labelled sketch together with your instrument or holder details, sample chemistry and target quantity. Discuss your requirements and quote part number C104SS18.
