(C502CA6) Glass Standard Cuvette, 50 mm Path, 17.5 mL

Weight	100 g

SKU: C502CA6

Original price was: $32.00.Current price is: $29.00.

In Stock

C502CA6 is a glass standard cuvette with a 50 mm optical path, 17.5 mL nominal capacity and an included lid for covered handling after filling. It is intended for methods within the stated 350–2000 nm range.

In Stock

SKU: C502CA6 Categories: Cuvettes, Glass Cuvettes, Products Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C502CA6 is a glass standard cuvette built around a 50 mm optical path and 17.5 mL nominal capacity. The longer rectangular body suits methods written for this path length, and the included lid gives you a covered format after filling. Its stated wavelength range is 350–2000 nm.

Path Length: 50 mm
Sample Volume (Nominal): 17.5 mL
Closure Type: Lid

Selection Specifications

Product Kind	Cuvette
Cell Type	Standard Cuvette
Measurement Mode	Absorbance Spectroscopy
Path Length	50 mm
Light Transmission Configuration	Two-Way Light
Wavelength Range — Lower Limit	350 nm
Wavelength Range — Upper Limit	2000 nm
Sample Volume (Nominal)	17.5 mL
External Dimensions	52.5 × 12.5 × 45 mm
Uncapped Cell Dimensions	52.5 × 12.5 × 45 mm
External Dimensions Scope	Uncapped Cell
Material	Glass
Closure Type	Lid
Closure Included	Yes

Choose this option

Choose C502CA6 when your application calls for a 50 mm path and you want a lidded glass cell rather than an uncovered body. The longer path and larger nominal capacity suit this extended sample region, while the lid can help keep the sample covered during routine handling between filling and measurement. This option is useful when your setup is based on the 50 mm format but does not require a stated sealed closure or pressure specification.

What makes this option different

50 mm optical path: match the measurement method to this transmission distance and align the beam through the sample region.
17.5 mL nominal capacity: plan the working fill and beam footprint together so liquid covers the illuminated region; nominal capacity is not a minimum working fill.
Accompanying closure: cover the opening after preparation and allow room to remove it; no pressure or leak-tight rating is specified.
Supplier-described fused integrated construction: keep the body assembled for routine cleaning and rinse through the sample opening, using liquids suitable for the complete glass assembly.

Using this cell

Fill the cuvette so the liquid level covers the measurement beam, then place the lid as needed for handling. Remove visible bubbles before measurement and keep the orientation consistent between blank and sample when your method depends on repeatable placement.

The 17.5 mL figure is a nominal capacity, not a minimum working volume. If you intend to work below a full fill, check in your own instrument that the liquid still covers the beam area.

First-use check

Before use, inspect the optical faces and edges for residue, scratches or transit damage. Rinse with a liquid suitable for your procedure, check that the lid seats properly, and confirm in the instrument that the filled sample covers the beam position.

Fit and optical alignment

The verified outer dimensions apply to the uncapped cell body: 52.5 × 12.5 × 45 mm. Use those dimensions to check holder seating, and leave additional top clearance because the overall size with the lid fitted is not established here.

Z Height is not available for this SKU. If your spectrometer or fixture depends on a fixed beam position, confirm beam alignment separately rather than relying only on the outside body dimensions.

Solvents and cleaning

The supplier records this cuvette as fused integrated construction, which suits routine bench use where the cell is handled and cleaned as one assembled body rather than taken apart between runs. That is the practical significance here: it supports straightforward rinse-and-refill handling, but it does not by itself define chemical compatibility for your sample or cleaning liquids.

Chemical limits are not established here for this exact body-and-lid combination. Use non-abrasive cleaning methods, and check your sample and cleaning conditions against your own process requirements before use. For a general overview of cuvette construction options, see Compare fabrication options.

Included with this option

This configuration includes an accompanying closure. Confirm the cell quantity and any separately specified accessories covered by your order.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

If you need a related cell with different dimensions, path length, closure details or another material, please send your drawing or holder information, critical dimensions, sample conditions and required quantity. You can discuss your requirements with us.
