(MQACC023) PTFE Screw Cap for Large-Neck 10 mm Cuvettes, 16 mm OD

Weight50 g
SKU: MQACC023

$17.00

In Stock

PTFE screw cap for the matching large-neck 10 mm path cuvette format. The 16 mm outer diameter and 12 mm cap height distinguish this larger cover, while the ribbed exterior provides a grip for hand fitting. Supplied as one cap; cuvette sold separately.

In Stock
Add to Wishlist
Add to Wishlist
Shipping and order support
  • Worldwide delivery to door service, hassle free shipping
  • Contact us for quotation of bulk purchase discount
  • Custom design. Send us graphic drawing for solution
  • POs for Academics. Pay after delivery.
  • Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

MQACC023 is a PTFE screw cap for the listed large-neck 10 mm path cuvette format. It is a separate closure accessory rather than a complete cell, so the practical points to check are the matching screw-cap style, the 16 mm outer diameter and the 12 mm body height. Those details help when you need a replacement cap that fits the cuvette top and still leaves room for handling in a holder or sampling setup.

Closure Type
Screw Cap

Selection Specifications

Product KindAccessory
Compatible Cuvette Path Length10 mm
Body Height12 mm
Outer Diameter (OD)16 mm
Closure TypeScrew Cap
Closure MaterialPTFE
Pack Quantity1 Piece
Sales Unitpiece
Package Contents1 × Cuvette cap/lid

Choose this option

Choose this cap when your existing cuvette uses the same large-neck screw-cap format for a 10 mm path cell and you want a separately supplied PTFE closure. It is most useful as a replacement or spare when the cuvette top already matches this cap style and the surrounding space can accommodate a 16 mm diameter cap body.

View the English selection reference.

What makes this option different

  • PTFE screw cap accessory for the listed large-neck cuvette format.
  • Associated with a 10 mm path cuvette style.
  • 16 mm outer diameter and 12 mm cap height, with outer ribs for hand fitting and removal.
  • Sold as 1 cap per piece.

Using this accessory

Install the cap by hand on a clean cuvette top with the cell supported during fitting and removal. Tighten only enough to seat it properly on the matching cuvette; avoid forcing the cap or using tools on the closure.

This item is intended as a separate closure component. It is useful when you need to close the cuvette opening during normal handling, filling or storage between steps, but it does not by itself define how the assembled cuvette will perform in a specific process.

First-use check

Inspect the cap and the cuvette top for dust, chips, residue or thread damage before first use. Test the fit gently on a clean empty cell before introducing sample.

Fit and installation

The most important fit point is the mating top of the cuvette, not the 10 mm path label alone. Check that your current cell uses the same large-neck screw-cap format, then compare the cap body size with the space available above and around the cuvette in your holder or fixture.

The 16 mm dimension is the cap outer diameter, not an M16 thread designation. The thread diameter, pitch and seating shape are not specified; match them to the existing cell. The larger cap body also needs turning clearance and space for your fingers around the neck.

English selection reference
Selection reference ↗

Handling and cleaning

Clean the cap with methods suitable for PTFE and for the full cuvette assembly it will be used with. This accessory does not on its own establish pressure capability, sealing performance or the chemical suitability of the complete assembled cuvette.

Included with this option

1 PTFE screw cap. Cuvettes are not included.

Availability and ordering

Order directly, or ask us about current availability and dispatch. Preparation time is separate from transit and customs clearance; ask before checkout if you need a particular delivery date.

Need a different fit?

For a different fit, send your cuvette SKU and mating dimensions or a drawing.
