(MQQFC019) Quartz Rectangular Sample Cell, 10 mm Path, 10 mL, Open at Both Ends

Weight150 g
SKU: MQQFC019

$599.00

In Stock

MQQFC019 is a JGS1 quartz rectangular sample cell with a 10 mm optical path, 10 mL nominal capacity and Four-Way Light access. Its tall open-at-both-ends body provides optical access from four sides for assemblies that need a straight chamber with more than one observation direction. Sold as 1 piece.

In Stock
Add to Wishlist
Add to Wishlist
Shipping and order support
  • Worldwide delivery to door service, hassle free shipping
  • Contact us for quotation of bulk purchase discount
  • Custom design. Send us graphic drawing for solution
  • POs for Academics. Pay after delivery.
  • Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

MQQFC019 combines a 10 mm optical path with a tall 10 mL rectangular chamber and Four-Way Light access. Made from JGS1 quartz, it is open at both ends and gives optical access from four sides of the body, which is useful when your setup needs transmission through one path while keeping side access available for observation or other supported optical geometry. The long straight chamber also makes the body easy to place in a custom holder.

Path Length
10 mm
Sample Volume (Nominal)
10 mL
Opening Configuration
Open at Both Ends

Selection Specifications

Product KindSpecialized Cell
Cell TypeRectangular Sample Cell
Measurement ModeTransmission Spectroscopy
Path Length10 mm
Light Transmission ConfigurationFour-Way Light
Wavelength Range — Lower Limit200 nm
Wavelength Range — Upper Limit2500 nm
Sample Volume (Nominal)10 mL
External Dimensions14 × 14 × 100 mm
Body Height100 mm
Base Dimensions14 × 14 mm
Internal Dimensions10 × 10 × 100 mm
MaterialQuartz
Material GradeJGS1
Fabrication MethodMolded 83
Opening ConfigurationOpen at Both Ends
Pack Quantity1 Piece

Choose this option

Choose MQQFC019 when you need a 10 mm path in a square-section quartz body with optical access from more than one side. This format suits custom assemblies that need a straight rectangular chamber, a tall sample region and open ends for user-defined filling or sealing methods.

View the English selection reference.

What makes this option different

  • Four-Way Light layout: optical access is available from four sides, which can help when the setup needs more than one side-facing optical direction.
  • 10 mm path with 10 mL nominal capacity: combines a familiar analytical path length with a tall straight sample chamber.
  • Square-section geometry: the 14 × 14 mm outer body around a 10 × 10 × 100 mm chamber is straightforward to review for holder clearance and chamber shape.
  • Open at both ends: sealing, sample retention and any liquid-handling interfaces come from your assembly, not from an integrated cap or fitting.

Structure and dimensions

Product dimensions for checking holder clearance and sample access.
Product dimensions for checking holder clearance and sample access.Open image ↗

Using this cell

Orient the cell so the measurement beam crosses the intended 10 mm path, then keep that orientation consistent for blank and sample readings. The Four-Way Light design adds side optical access, but the mounted beam position and instrument fit still need to match your actual holder.

The 10 mL value is the nominal chamber capacity, not a minimum working volume. For liquid use, establish your end support, filling and bubble-control procedure in the assembled setup before routine measurements.

First-use check

  1. Inspect the optical faces and both open ends before installation.
  2. Place the cell in the holder and verify beam alignment through the intended path without clipping.
  3. Test the filling and retention method with a blank and check for bubbles or leakage in the full assembly.

Fit and optical alignment

Check holder clearance against the full 14 × 14 × 100 mm outer body. The internal 10 × 10 × 100 mm dimensions describe the chamber only and should not be treated as external fit dimensions.

Z Height is not specified for this SKU. If your instrument requires a fixed beam-center height, confirm that in the mounted assembly rather than assuming compatibility from the outer shape alone.

English selection reference
Selection reference ↗

Solvents and cleaning

This cell is classed as Molded 83. This fabrication type is commonly chosen for methods that may involve organic solvents or elevated-temperature use, but suitability still depends on the complete assembly and the actual chemicals, temperature and exposure time in your process.

Keep hydrofluoric acid away from quartz. Avoid hot strong alkalis and abrasive cleaning methods. Clean the optical faces gently with a suitable non-abrasive, lint-free wipe.

Included with this option

1 MQQFC019 rectangular sample cell. The listed price is for one cell.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz versions for changes to path length, chamber size, outer envelope, openings and holder-related geometry. If you need a different body format or a cell matched to a specific optical layout, send a labelled sketch or drawing with the critical dimensions and sample conditions.

Send a product-selection enquiry with SKU MQQFC019 and your holder or optical layout details.
