(MQQMC082) Quartz Flow Cell, 0.5 mm path, 80 µL nominal capacity, Bent-Tube Connection Layout

Weight	80 g

SKU: MQQMC082

Quartz Flow Cell, 0.5 mm path, 80 µL nominal capacity, Bent-Tube Connection Layout

Product dimensions for checking holder clearance and sample access.

$768.00

In Stock

MQQMC082 is a JGS1 quartz flow cell with a 0.5 mm optical path, 80 µL nominal capacity and a flat 40 × 3 × 12 mm body. Two tube connections sit on one broad face, keeping the fluid routing on the same side of the cell. The listed price is for 1 piece.

In Stock

SKU: MQQMC082 Categories: Cuvettes, Products, Quartz Micro Cuvettes Tags: Cuvettes, Quartz Micro Flow Cell

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

MQQMC082 is a JGS1 quartz flow cell for UV/Vis measurements that use a short 0.5 mm optical path in a flat body. Its 80 µL nominal capacity, 20 × 8 × 0.5 mm internal cavity and same-face tube layout make it useful when the optical path must stay short and the tubing needs to approach from one side of the assembly.

Path Length: 0.5 mm
Sample Volume (Nominal): 80 µL
Opening Configuration: Two Tubes on One Face

Selection Specifications

Product Kind	Flow Cell
Cell Type	Flow Cell
Measurement Mode	UV/Vis Spectroscopy
Path Length	0.5 mm
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	80 µL
External Dimensions	40 × 3 × 12 mm
Cell Body Dimensions	40 × 3 × 12 mm
Internal Dimensions	20 × 8 × 0.5 mm
Material	Quartz
Material Grade	JGS1
Port Count	2
Tube Outer Diameter (OD)	3 mm
Tube Inner Diameter (ID)	2 mm
Fabrication Method	Molded 83
Opening Configuration	Two Tubes on One Face
Port Layout	One broad face near end A, shown on the left; Same broad face near end B, shown on the right
Pack Quantity	1 Piece
Package Contents	1 × Quartz Flow Cell

Choose this option

Choose this cell when your fixture favors a low-profile flow body rather than a taller cuvette-style format. The flat body can be easier to place in compact assemblies, while the two tubes on one broad face keep the fluid connections grouped on the same side instead of splitting them across opposite ends.

What makes this option different

0.5 mm optical path for short-path UV/Vis measurements.
80 µL nominal capacity with a 20 × 8 × 0.5 mm internal cavity.
Flat 40 × 3 × 12 mm body for low-profile installation in a suitable holder.
Two 3 mm OD / 2 mm ID tubes on one broad face to keep the connection direction on the same side of the cell.

Structure and dimensions

Using this cell

Support the cell by the body during installation and avoid using the projecting tubes as handles. Fill the cavity slowly and inspect the optical region before measurement so bubbles or streaks do not remain across the short path.

Keep the orientation consistent once the cell is aligned in the holder. The nominal 80 µL value describes the capacity of the cell itself; the total liquid volume of your setup will be higher once connected tubing and other flow-path parts are included.

First-use check

Inspect the optical faces, cavity area and tube ends before installation.
Place the cell in the holder with a suitable blank and verify that the beam crosses the intended optical region.
After filling, remove bubbles and exterior droplets, then repeat the blank in the same seated position.

Fit and optical alignment

View the English selection reference.

The 40 × 3 × 12 mm dimensions apply to the body only. The tubes project beyond that body envelope, so leave extra clearance for tube bends, attached lines and the direction of entry into your fixture.

No Z Height is established for this SKU. If your instrument or holder depends on a defined beam-center height from the base, check that point before ordering instead of relying on the outer body size alone.

English selection reference — Selection reference ↗

Solvents and cleaning

This cell uses Molded 83 quartz construction. This fabrication is commonly selected for organic-solvent methods and applications that may involve temperature, but suitability still depends on the complete wetted assembly and your actual conditions.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning. For aggressive liquids, elevated temperature or long contact time, check the full sample and cleaning conditions before use.

Included with this option

1 Quartz Flow Cell.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We can review custom JGS1 quartz versions for changes to body size, optical path length, cavity dimensions, tube layout, beam-height requirements and related tolerances. Send a dimensioned sketch or drawing together with holder details, sample conditions and required quantity. Send a product-selection enquiry with SKU MQQMC082.
