(C104CS50) Quartz Micro Cuvette, 10 mm / 5 mm (dual path) Path, 1.75 mL

Weight	30 g

SKU: C104CS50

Original price was: $72.00.Current price is: $65.00.

In Stock

JGS1 quartz micro cuvette for fluorescence spectroscopy with a 10 mm primary path, 5 mm secondary path and Four-Way Light access. This adhesive-bonded Standard 80 option has a 1.75 mL nominal capacity and is intended for neutral water-based sample conditions rather than acid, alkali or organic-solvent use. Supplied as 1 quartz micro cuvette, with a closure included.

In Stock

SKU: C104CS50 Categories: Cuvettes, Products, Quartz Fluorescence Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C104CS50 is a JGS1 quartz micro cuvette for fluorescence spectroscopy with a 10 mm primary path, a 5 mm secondary path and Four-Way Light access around the sample region. This version uses adhesive-bonded Standard 80 construction, so it suits neutral water-based sample conditions rather than acid, alkali or organic-solvent work. Its nominal capacity is 1.75 mL, and this sales option is supplied as 1 quartz micro cuvette, with a closure included.

Path Length: 10 mm / 5 mm (dual path)
Sample Volume (Nominal): 1.75 mL
Closure Type: Lid

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	Fluorescence Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm / 5 mm (dual path)
Light Transmission Configuration	Four-Way Light
Optical Window Dimensions	5 mm
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	1.75 mL
External Dimensions	12.5 × 12.5 × 45 mm
Uncapped Cell Dimensions	12.5 × 12.5 × 45 mm
External Dimensions Scope	Uncapped Cell
Material	Quartz
Material Grade	JGS1
Closure Type	Lid
Closure Included	Yes
Fabrication Method	Standard 80
Detection Channel Width	5 mm

Choose this option

Choose this cuvette when you need the stated 10 mm / 5 mm dual-path fluorescence geometry and your sample conditions fit an adhesive-bonded quartz cell for neutral aqueous work. The four-side optical access supports fluorescence layouts around the sample region, while the chemical limits make this version a practical choice only where water-based handling and cleaning are suitable.

What makes this option different

10 mm / 5 mm dual-path geometry for methods using two stated optical directions in one compact cell.
Four-Way Light configuration for optical access from four sides around the sample region.
Standard 80 adhesive-bonded construction suited to room-temperature neutral water-based samples and buffers.
Supplier chemical limits exclude acid, alkali and organic-solvent use, including ethanol soaking or rinsing.

Using this cell

Fill the cell so the illuminated region is covered during measurement, and keep the same orientation for blank and sample runs. If your method uses side optical access or the secondary path, repeatable seating helps keep the same sample geometry from run to run.

The 1.75 mL figure is the nominal capacity of the cell, not a minimum working volume. If your instrument uses a fixed beam height or a small beam footprint, confirm the practical fill level in the actual holder before routine use.

First-use check

Inspect the optical faces, chamber and closure seating area before first use.
Place the empty cell in the holder to confirm body fit and top clearance.
Run a blank in the intended orientation and verify that the beam crosses the intended sample region.
Confirm that the fill level covers the illuminated area without bubbles or residue on the optical faces.

Fit and optical alignment

The stated external dimensions, 12.5 × 12.5 × 45 mm, apply to the uncapped cell body. Use those body dimensions to check holder fit and insertion clearance, and leave extra room above the cell because the installed height with the closure is not established here.

Z Height is not available for this SKU. If your fluorescence holder or optical bench depends on a defined beam-centre height, check that point in your own setup rather than assuming fit from the external body size alone.

Solvents and cleaning

This cuvette uses Standard 80 adhesive-bonded quartz construction. This MQ fabrication option is generally used for room-temperature water-based samples and buffers, and it should be selected with the full sample and cleaning routine in mind.

For this exact option, the supplier excludes acid, alkali and organic-solvent use, and also prohibits ethanol soaking or rinsing. Do not use hydrofluoric acid with quartz, avoid hot strong alkalis and abrasive cleaning, and wipe the exterior optical faces gently with non-abrasive optical tissue.

Included with this option

1 quartz micro cuvette with lid.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz versions for changes to dimensions, optical path length, sample volume, optical windows, Z Height, closures and fabrication requirements. If your method needs different chemical resistance or a different geometry, send a drawing or labelled sketch together with holder details, sample conditions and target quantity for review. Discuss your requirements and mention part number C104CS50.
