Quartz 10mm Quartz Two-Way Cuvette, 27ml, Sintered 83, Two-way Light, No Cover, 1pc/ea, C102CR23
10%
USD$218.00 USD$197.00
Quartz 10 mm two-way oversized cuvette, 27ml, Sintered 83 (>83% transmittance). Two-Way Light. 190–2500 nm. No Cover. SKU: C102CR23. In Stock.
Description
The C102CR23 is a precision quartz two-way oversized cuvette featuring a 10mm optical path length and 27ml internal volume. The Sintered 83 fabrication delivers superior optical purity with excellent deep-UV transmission below 200nm. With Two-Way Light configuration allows measurement from both polished faces, this cuvette ships without a cover for rapid sample loading and easy cleaning and delivers reliable performance for demanding spectroscopic applications.
Technical Specifications — Two-Way Oversized Cuvette
| Specifications | |||
|---|---|---|---|
| Material | Quartz (Fused Silica) | SKU | C102CR23 |
| Type | Two-Way Oversized Cuvette | Path Length | 10 mm |
| Internal Volume | 27ml | Fabrication | Sintered 83 |
| Transmittance | >83% | Wavelength | 190–2500 nm |
| Optical Windows | 2 (Two-Way Light) | Exterior Dimensions | 54 × 14 × 60 mm |
| Interior Dimensions | 50 × 10 × 58 mm | Cap Type | No Cover |
| Package | 1pc/ea | ||
Applications
◆ UV-Vis Spectrophotometry
◆ Large-Body Two-Way Optical Measurement
◆ Standard Volume Spectroscopy
◆ Routine Chemical Analysis
◆ Deep-UV Spectral Analysis
◆ Fluorescence Spectroscopy
Why a Two-Way Oversized Cuvette?
Two-way oversized cuvettes combine expanded body dimensions with precision optical surfaces on two opposing faces. The C102CR23‘s 10 mm path and 27ml volume — housed in a 54 × 14 × 60 mm exterior frame with 50 × 10 × 58 mm internal chamber — accommodates larger sample quantities and reduces filling artifacts. The oversized body provides better thermal uniformity and minimizes wall effects for more accurate readings.
Why Sintered 83?
The Sintered 83 process fuses high-purity quartz granules at elevated temperatures, producing a cell with excellent deep-UV transmittance down to 190 nm and minimal fluorescence background. This makes the C102CR23 suitable for demanding UV applications including nucleic acid quantification and protein analysis at 260/280 nm.
Usage Tips
Handling: Always hold the cuvette by its frosted or unpolished surfaces to prevent fingerprints on optical windows. Clean with spectroscopic-grade solvents and lint-free wipes. For best results, rinse with your sample solution before final filling to minimize dilution effects. Store upright in a padded container to protect the polished optical faces.
Custom Orders
Need a modified path length, special coating, or custom dimensions? We manufacture quartz cuvettes to your exact specifications. Contact our team to discuss your requirements.
Specifications are nominal values measured under standard conditions. Actual performance may vary slightly. All quartz cuvettes are manufactured from high-purity synthetic quartz glass. Images are representative; actual product appearance may differ.
Additional information
| Weight | 100 g |
|---|
