(C102CE28) Quartz Ultra-Micro Cuvette, 10 mm Path, 200 µL

Weight	30 g

SKU: C102CE28

Original price was: $84.00.Current price is: $76.00.

In Stock

C102CE28 is a JGS1 quartz ultra-micro cuvette with a 10 mm optical path, 200 µL nominal capacity and a 15 mm Z Height. Its open-top format supports direct pipette filling, and the included lid covers the opening during routine upright handling. Sold as 1 cuvette per listed MQ sale unit.

In Stock

SKU: C102CE28 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C102CE28 is a quartz ultra-micro cuvette for UV/Vis work from 200 to 2500 nm when you need a standard 10 mm path in a compact body. This option pairs a 200 µL nominal capacity with a 15 mm Z Height, which is often the deciding fit detail when your holder places the beam higher above the base. The open top gives direct access for filling, and a lid is included for covered upright handling.

Path Length: 10 mm
Sample Volume (Nominal): 200 µL
Opening Configuration: Open Top

Selection Specifications

Product Kind	Cuvette
Cell Type	Ultra-Micro Cuvette
Measurement Mode	UV/Vis Spectroscopy
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Z Height	15 mm
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	200 µL
External Dimensions	12.5 × 12.5 × 45 mm
Cell Body Dimensions	12.5 × 12.5 × 45 mm
External Dimensions Scope	Body Only
Body Height	45 mm
Base Dimensions	12.5 × 12.5 mm
Material	Quartz
Material Grade	JGS1
Closure Type	Lid
Closure Included	Yes
Fabrication Method	Standard 80
Opening Configuration	Open Top

Choose this option

Choose C102CE28 when your method needs a 10 mm path but your instrument or holder is set for a 15 mm beam-centre height. The 200 µL nominal capacity makes it suitable for small-volume measurements without changing to a shorter optical path, and the open-top format keeps loading simple for direct pipetting and visual checking before measurement.

What makes this option different

15 mm Z Height helps match holders or instruments with a higher beam position from the base.
10 mm optical path keeps the familiar absorbance path length in an ultra-micro cell format.
200 µL nominal capacity suits methods that work with limited sample volume.
Open-top body allows direct filling and easy access to the sample region.
Lid included covers the opening during normal upright handling after filling.
Two-Way Light layout supports transmission across the main optical path only.

Using this cell

Fill the cell from the top and make sure the illuminated region is fully covered before you start a run. With a small nominal volume, careful pipetting and bubble control matter, especially near the optical faces.

The lid is useful when you want the filled cell covered during routine bench handling or while moving it into the holder. This page does not establish a sealed, leak-tight or pressure-rated closure, so the cell should be selected for upright use rather than closed-loop, inverted or pressurised operation.

First-use check

Inspect the optical faces and upper opening for dust, residue or handling marks.
Place the empty cell in the holder and confirm that it seats squarely.
Check that your beam aligns to a 15 mm optical centre from the base.
Run a blank at your intended fill level to confirm beam coverage and bubble-free loading.

Fit and optical alignment

The body dimensions are 12.5 × 12.5 × 45 mm, and these dimensions apply to the cell body rather than a full capped envelope. Check holder seating and top clearance if nearby hardware sits close to the opening or lid area.

The optical centre is 15 mm above the base. Match that Z Height to your instrument beam position before ordering. The 200 µL figure is a nominal capacity, not a minimum working volume, so your actual fill level still needs to cover the beam in your own measurement setup.

Solvents and cleaning

This cuvette uses Standard 80 adhesive-bonded quartz construction. For this type of assembly, routine water-based samples and buffers at room temperature are the normal selection direction. Avoid organic samples and organic cleaning solvents with this adhesive-bonded cell.

The exact chemical limits for this specific assembly are not established here, so if your sample or cleaning routine involves aggressive chemicals, mixed solvent systems or long contact time, check suitability before use. Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning methods, and wipe optical faces gently with non-abrasive laboratory or optical tissue.

Included with this option

One open-top quartz ultra-micro cuvette in the listed specification, supplied with a lid.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz production for requirements involving dimensions, optical path length, sample volume, optical windows or Z Height, closures and fabrication details. Send a dimensioned drawing or labelled sketch and identify the dimensions that matter most in your holder or instrument. Prototype batches typically involve 2–4 cells; final specifications, quantity, price and production time are confirmed in the project quotation. Discuss your requirements and quote part number C102CE28.
