(C102CD6) Quartz Ultra-Micro Cuvette, 10 mm Path, 200 µL

Weight	30 g

SKU: C102CD6

Original price was: $98.00.Current price is: $89.00.

In Stock

C102CD6 is a quartz ultra-micro cuvette with a 10 mm optical path, Two-Way Light layout and 200 µL nominal capacity. Its open-top body gives direct pipette access, and a closure is included for covered handling after filling. Sold as 1 cuvette per price unit.

In Stock

SKU: C102CD6 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C102CD6 is a quartz ultra-micro cuvette for methods that need a 10 mm optical path in a small-volume cell. It combines a 200 µL nominal capacity with a Two-Way Light layout and an open-top body, so you can load the sample directly from above while keeping the familiar 12.5 × 12.5 mm cuvette footprint for holder planning.

This option suits routine transmission measurements across the main optical faces when you want a compact sample chamber rather than a full-volume standard cell. A closure is included, but the opening remains an open-top configuration, so selection should be based on sample access and holder fit rather than an assumed sealed assembly.

Path Length: 10 mm
Sample Volume (Nominal): 200 µL
Opening Configuration: Open Top

Selection Specifications

Product Kind	Cuvette
Cell Type	Ultra-Micro Cuvette
Measurement Mode	UV/Vis Spectroscopy
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Sample Volume (Nominal)	200 µL
External Dimensions	12.5 × 12.5 × 45 mm
Cell Body Dimensions	12.5 × 12.5 × 45 mm
External Dimensions Scope	Body Only
Material	Quartz
Closure Type	Lid
Closure Included	Yes
Opening Configuration	Open Top

Choose this option

Choose C102CD6 when your method calls for a 10 mm path length but your sample volume is limited enough that a 200 µL nominal chamber is a better fit than a larger cuvette. The open top makes filling, checking the liquid level and changing samples straightforward, especially when you work by pipette. Its quartz construction also makes it suitable for UV and visible-light use where a quartz cell is required.

What makes this option different

10 mm optical path for methods that are set up around this path length in a smaller-format cell.
200 µL nominal capacity for small-sample loading, while still requiring enough liquid to cover the illuminated region in your own setup.
Open-top access for direct filling, inspection and sample exchange from above.
Closure included so the filled cell can be covered during handling, without implying a defined seal, pressure rating or inversion use.
Two-Way Light configuration for transmission through the main optical faces rather than side-access optical layouts.
12.5 × 12.5 × 45 mm body dimensions for checking holder seating and vertical clearance around the installed cell body.

Using this cell

Fill the cell from the top opening with a pipette or similar controlled transfer method. Before measurement, make sure the sample fully covers the beam region used by your instrument and that no bubbles remain in the optical path.

Use the same orientation for blank and sample measurements so the cell sits consistently in the holder. After filling, the included closure can be placed over the opening for covered handling, but this should not be treated as a stated leak-tight or pressure-capable arrangement.

First-use check

Inspect the optical faces for dust, residue or handling marks before first use.
Place the cell in your holder and confirm stable seating and unobstructed beam access.
Run a blank at your intended fill level to check that the beam passes fully through liquid and remains free of bubbles.

Fit and optical alignment

The body dimensions are 12.5 × 12.5 × 45 mm for the optical cell body itself. This helps you check holder fit and top clearance, especially if your compartment or accessory sits close above the rim area.

Z Height is not established here, so do not assume beam-height compatibility from the external body size alone. If your instrument has a fixed beam position, verify that the filled sample region will align with that beam in your holder.

Solvents and cleaning

Chemical limits for this exact assembly are not established here, so check your sample and cleaning liquids against the full wetted construction before using aggressive chemicals. This is especially important if your method depends on a specific solvent routine.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning methods, and clean the exterior optical faces gently with non-abrasive optical tissue.

Included with this option

1 cuvette per listed price unit. Closure included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We can review custom quartz versions for changes to dimensions, path length, sample volume, optical windows or Z Height, closures and fabrication requirements. Send your drawing or labelled sketch, instrument or holder details, sample conditions and target quantity through our contact page, and refer to part number C102CD6.
