(C202TR) Quartz Screw-Top Cuvette, 20 mm Path, 7 mL

Weight	100 g
Dimensions	2.25 × 1.25 × 5.6 mm

SKU: C202TR

Original price was: $190.00.Current price is: $171.00.

In Stock

C202TR is a JGS1 quartz screw-top cuvette for UV/Vis work with a 20 mm optical path, Two-Way Light layout and 7 mL nominal capacity. Its single threaded neck and included PTFE screw cap suit methods that need a covered sample cell with direct top filling. Sold as 1 cuvette with 1 PTFE cap.

In Stock

SKU: C202TR Categories: Cuvettes, Products, Quartz Screw-Top Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C202TR is a JGS1 quartz screw-top cuvette built around a 20 mm optical path for UV/Vis measurements. This version combines a 7 mL nominal capacity, Two-Way Light layout and a single threaded neck with an included PTFE screw cap, giving you a covered transmission cell with direct top access for routine filling and handling.

It is a practical choice when you want a longer-than-standard path in a relatively slim rectangular body instead of a wider large-volume format. The included PTFE cap is useful when your workflow calls for a covered sample chamber during preparation and measurement.

Path Length: 20 mm
Sample Volume (Nominal): 7 mL
Opening Configuration: Single Threaded Neck

Selection Specifications

Product Kind	Cuvette
Cell Type	Screw-Top Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	20 mm
Light Transmission Configuration	Two-Way Light
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	7 mL
External Dimensions	22.5 × 12.5 × 45 mm
Body Height	45 mm
Base Dimensions	22.5 × 12.5 mm
Material	Quartz
Material Grade	JGS1
Closure Type	Screw Cap
Closure Material	PTFE
Closure Included	Yes
Opening Configuration	Single Threaded Neck

Choose this option

Choose C202TR when your method is written for a 20 mm path length and you want a screw-top quartz cell rather than an open-top cuvette. The 7 mL nominal capacity and narrow rectangular body make it suited to routine UV/Vis transmission work where covered top access matters.

What makes this option different

20 mm optical path for methods built around this defined transmission distance.
7 mL nominal capacity in a rectangular screw-top cell.
Single threaded neck with PTFE screw cap included for direct top filling in a covered format.
Two-Way Light layout for transmission through two opposing optical faces.

Using this cell

Fill through the threaded top opening so the liquid covers the beam during measurement, then seat the PTFE cap after filling. Keep the optical faces free of droplets, fingerprints and bubbles, and use the same orientation for blank and sample runs where method consistency matters.

The 7 mL figure is the nominal capacity of the cell, not a minimum working volume. If you plan to run at reduced fill levels, check that the sample still covers the illuminated region in your instrument.

First-use check

Inspect the optical faces, thread area and cap for residue or handling marks.
Rinse with a cleaning liquid suitable for your method and the full assembly.
Run a blank and confirm that the filled sample covers the beam without bubbles.

Fit and optical alignment

The bare optical body is 22.5 × 12.5 × 45 mm, with a 22.5 × 12.5 mm base. These dimensions are useful for checking holder width, depth and body support, but they do not include the full neck and closure envelope.

Z Height is not established for this SKU. If your instrument has a fixed beam height or tight vertical clearance, confirm beam position and holder fit before ordering rather than relying on body size or path length alone.

Solvents and cleaning

Quartz is used here for UV/Vis transmission, but specific chemical, concentration, temperature and contact-time limits are not established for this full assembly. If your sample or cleaning routine is chemically demanding, check suitability before use.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning materials. Clean the optical faces gently with non-abrasive materials suitable for optical surfaces. For general background on cuvette construction types, see Compare fabrication methods.

Included with this option

Price is for 1 cuvette. A PTFE screw cap is included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz versions for changes involving dimensions, optical path length, sample volume, optical windows, Z Height, closures and related fit requirements. Send a dimensioned drawing or labelled sketch together with your holder details and sample conditions. Discuss your requirements and quote part number C202TR.
