(C502CA5) Quartz Large-Window Cuvette, 10 mm Path, 17.5 mL

Weight	100 g

SKU: C502CA5

Original price was: $123.00.Current price is: $111.00.

In Stock

C502CA5 is a JGS1 quartz large-window cuvette for UV/Vis spectroscopy with a 10 mm optical path and 17.5 mL nominal capacity. It suits methods that keep a standard 10 mm path but need a much larger sample chamber and a longer large-window body for holder planning. Sold as 1 cuvette, with lid included.

In Stock

SKU: C502CA5 Categories: Cuvettes, Products, Quartz Large Window Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C502CA5 is a JGS1 quartz large-window cuvette for UV/Vis work with a 10 mm optical path and 17.5 mL nominal capacity. It is suited to methods that keep the standard 10 mm measurement path but need a larger sample chamber and a longer body than a compact routine cell. This option is sold as 1 cuvette, with lid included.

Path Length: 10 mm
Sample Volume (Nominal): 17.5 mL
Closure Type: Lid

Selection Specifications

Product Kind	Cuvette
Cell Type	Large-Window Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	17.5 mL
External Dimensions	52.5 × 12.5 × 45 mm
Cell Body Dimensions	52.5 × 12.5 × 45 mm
External Dimensions Scope	Body Only
Material	Quartz
Material Grade	JGS1
Closure Type	Lid
Closure Included	Yes

Choose this option

Choose C502CA5 when your method uses a 10 mm path but your sample handling or chamber planning calls for a larger-volume quartz cell. The 17.5 mL nominal capacity is useful when you want more liquid in the cell body, and the longer large-window format gives a different physical fit from smaller cuvette bodies even though the optical path remains 10 mm.

What makes this option different

10 mm optical path for standard UV/Vis measurement methods.
17.5 mL nominal capacity in a larger-body cuvette.
JGS1 quartz construction for UV/Vis use.
52.5 × 12.5 × 45 mm body dimensions, stated for the body only.

Using this cell

Fill the cuvette so the liquid fully covers the beam during measurement, and remove visible bubbles before reading. Keep the same orientation for blank and sample runs, and handle the cell by non-optical surfaces where possible to keep the viewing faces clean.

The nominal capacity describes the cell volume, not a minimum working volume. If your method runs at a lower fill level or depends on a fixed beam height, verify that the liquid level stays above the beam in your own instrument because Z Height is not stated for this SKU.

First-use check

Inspect the optical faces for visible residue, chips, scratches or fingerprints.
Place the empty cell in the holder to confirm seating and chamber clearance before filling.
Check a filled blank to make sure the intended beam area is covered and free of bubbles.

Fit and optical alignment

The stated body dimensions are 52.5 × 12.5 × 45 mm. These dimensions apply to the body only, so use them to check holder seating and side clearance, then allow additional room for the included lid because the assembled height is not stated here.

This cuvette is listed for UV/Vis spectroscopy, but body dimensions alone do not guarantee fit in a particular spectrometer or accessory holder. If your instrument has a fixed beam position, top clamp or limited chamber height, confirm those requirements before ordering.

Solvents and cleaning

The exact chemical limits of this cell assembly are not stated here. For general background on cuvette construction choices and how sample and cleaning routine can affect selection, see Compare fabrication methods.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning. Wipe the exterior optical faces gently with non-abrasive optical tissue.

Included with this option

Price is for 1 cuvette. A lid is included. Other package contents are not specified here.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

If you need a different body size, path length, capacity, optical layout, Z Height or closure arrangement, we can review a custom JGS1 quartz version. Send your drawing or labelled sketch, holder or instrument details, critical dimensions, sample conditions and target quantity through Discuss your requirements.
