(C102SR14) Quartz Micro Cuvette, 10 mm Path, 350 µL
10%
Original price was: $143.00.$129.00Current price is: $129.00.
C102SR14 is a JGS1 quartz micro cuvette for UV/Vis work with a 10 mm optical path, Two-Way Light layout and 350 µL nominal capacity. It uses a 1 mm sample channel and includes a stopper. Supplied as 1 cuvette.
In Stock
Description
C102SR14 is a JGS1 quartz micro cuvette for UV/Vis methods that need a standard 10 mm path in a smaller filled format. It combines Two-Way Light transmission with a 350 µL nominal capacity and a 1 mm sample channel, giving you a straightforward front-to-back optical layout in a compact square body. This option is supplied as 1 cuvette with a stopper included.
- Path Length
- 10 mm
- Sample Volume (Nominal)
- 350 µL
- Closure Type
- Stopper
Selection Specifications
| Product Kind | Cuvette |
|---|---|
| Cell Type | Micro Cuvette |
| Measurement Mode | UV/Vis Spectroscopy |
| Pack Quantity | 1 Piece |
| Path Length | 10 mm |
| Light Transmission Configuration | Two-Way Light |
| Optical Window Dimensions | 1 mm |
| Wavelength Range — Lower Limit | 200 nm |
| Wavelength Range — Upper Limit | 2500 nm |
| Sample Volume (Nominal) | 350 µL |
| External Dimensions | 12.5 × 12.5 × 45 mm |
| Base Dimensions | 12.5 × 12.5 mm |
| Material | Quartz |
| Material Grade | JGS1 |
| Closure Type | Stopper |
| Closure Included | Yes |
| Detection Channel Width | 1 mm |
Choose this option
Choose C102SR14 when your method is built around a 10 mm UV/Vis path but your sample plan fits a micro cuvette rather than a larger square cell. The Two-Way Light layout keeps the optical arrangement simple, and the stopper-equipped format is useful when you want the sample covered between filling and measurement.
What makes this option different
- 10 mm optical path for UV/Vis methods set up around this standard path length.
- Two-Way Light configuration with a direct front-to-back beam direction.
- 350 µL nominal capacity with a 1 mm sample channel.
- JGS1 quartz body in a 12.5 × 12.5 × 45 mm external format with stopper included.
Using this cell
Fill the cuvette so the illuminated region is fully covered, and remove bubbles from the optical path before measurement. Keep the same orientation for blank and sample so the beam always passes through the same faces.
The stated 350 µL is a nominal capacity, not a minimum working volume. If your method is sensitive to fill level, check the liquid height in your own instrument before routine use.
First-use check
Inspect the optical faces for residue, chips or scratches before first use. Test-fit the cuvette in your holder, rinse with a suitable blank, and confirm that the beam passes through the intended filled region without bubbles. Insert and remove the stopper gently to check routine handling.
Fit and optical alignment
The external dimensions are 12.5 × 12.5 × 45 mm, with a 12.5 × 12.5 mm base. This helps with holder seating and general clearance planning around the stopper area.
Z Height is not specified for this cuvette, so outside dimensions alone do not establish beam-center fit in a fixed-beam instrument. The 1 mm value refers to the sample channel width, not to beam height.
Solvents and cleaning
This quartz micro cuvette uses fused integrated construction. For general background on MQ cuvette construction options, see the fabrication guide.
Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning. Rinse promptly after use and wipe the optical faces gently with non-abrasive laboratory or optical tissue. If your sample or cleaning routine involves aggressive chemicals or long contact times, check suitability before routine use.
Included with this option
1 cuvette per listed price unit. Closure included.
Availability and ordering
Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.
Discuss a custom version
We can review custom JGS1 quartz versions for different path lengths, sample volumes, outside dimensions, optical layouts or holder-related geometry. Send your drawing or labelled sketch, holder or instrument details, critical dimensions and sample conditions through this contact page, and quote part number C102SR14.
