(C102SR15) Quartz Micro Cuvette, 10 mm Path, 700 µL
10%
Original price was: $143.00.$129.00Current price is: $129.00.
C102SR15 is a JGS1 quartz micro cuvette for UV/Vis spectroscopy with a 10 mm optical path, 700 µL nominal capacity and a stopper closure. Its Two-Way Light layout and 2 mm sample-region width make it a practical choice when you need a covered micro-volume cell in a familiar 12.5 × 12.5 mm footprint. Sold as 1 cuvette.
In Stock
Description
C102SR15 is a JGS1 quartz micro cuvette for UV/Vis work when you need a standard 10 mm optical path in a smaller-volume format. This version combines a 700 µL nominal capacity, a 2 mm sample-region width and an included stopper, so it suits routine covered measurements while keeping the familiar square cuvette footprint for holder planning.
The cell uses a Two-Way Light layout and is intended for transmission measurements through the main opposing optical faces. Its stated 200–2500 nm wavelength range and quartz body make it suitable for UV/Vis methods within that range, while the compact sample region helps define where the liquid sits in the measurement area.
- Path Length
- 10 mm
- Sample Volume (Nominal)
- 700 µL
- Closure Type
- Stopper
Selection Specifications
| Product Kind | Cuvette |
|---|---|
| Cell Type | Micro Cuvette |
| Measurement Mode | UV/Vis Spectroscopy |
| Pack Quantity | 1 Piece |
| Path Length | 10 mm |
| Light Transmission Configuration | Two-Way Light |
| Optical Window Dimensions | 2 mm |
| Wavelength Range — Lower Limit | 200 nm |
| Wavelength Range — Upper Limit | 2500 nm |
| Sample Volume (Nominal) | 700 µL |
| External Dimensions | 12.5 × 12.5 × 45 mm |
| Base Dimensions | 12.5 × 12.5 mm |
| Material | Quartz |
| Material Grade | JGS1 |
| Closure Type | Stopper |
| Closure Included | Yes |
| Detection Channel Width | 2 mm |
Choose this option
Choose C102SR15 when your method needs a 10 mm path but you do not want the larger nominal fill of a full-volume cell. The 700 µL nominal capacity and 2 mm sample-region width are useful when you want a covered micro cuvette that still fits the common 12.5 × 12.5 mm holder format. This is also a straightforward option when you prefer a stopper at the top rather than an open filling chamber.
What makes this option different
- 10 mm optical path for methods built around the standard cuvette path length.
- 700 µL nominal capacity in a micro cuvette format for moderate sample fills.
- 2 mm sample-region width to define a narrow measurement region within the cell.
- Stopper included for a covered sample chamber after filling.
Using this cell
Fill the cell so the illuminated region is fully covered, then insert the stopper gently. Keep the same orientation for blank and sample measurements so the same optical faces are used each time.
The 700 µL figure is the nominal cell capacity, not a minimum working volume. In routine use, set your own fill practice by checking that the liquid level covers your beam position without trapped bubbles.
First-use check
- Inspect the optical faces and stopper area for dust or handling residue.
- Test the cuvette in your holder and confirm there is enough top clearance for insertion and removal.
- Run a blank at your intended fill level and confirm that the beam passes fully through the filled region without bubbles.
Fit and optical alignment
The stated outer dimensions are 12.5 × 12.5 × 45 mm, with a 12.5 × 12.5 mm base. That square base is useful for checking holder fit in standard cuvette holders, while the top closure means you should also allow clearance above the cell for filling and stopper handling.
Z Height is not specified for this SKU. If your instrument has a fixed beam center height or a micro-volume accessory with limited vertical tolerance, check beam alignment against the actual sample region before ordering rather than relying on the outside size alone.
Solvents and cleaning
This cuvette is intended for UV/Vis laboratory use. Do not use hydrofluoric acid on quartz, and avoid hot strong alkalis and abrasive cleaning.
Chemical compatibility for the complete wetted assembly is not established here, including the closure parts. If your sample or cleaning method involves aggressive chemicals or organic solvents, please check suitability before ordering. For general background on MQ cuvette constructions, see Compare fabrication options.
Included with this option
1 cuvette per listed price unit. Closure included.
Availability and ordering
Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.
Discuss a custom version
If you need a different path length, nominal capacity, opening style or holder-related geometry, we can review a custom quartz version for your application. Send a dimensioned drawing or labelled sketch, your holder details and sample conditions through our contact page, and mention part number C102SR15.
Additional information
| Weight | 30 g |
|---|
