(C102SS21) Quartz Micro Cuvette, 10 mm Path, 350 µL

Weight	30 g

SKU: C102SS21

Original price was: $72.00.Current price is: $65.00.

In Stock

C102SS21 is a quartz micro cuvette with a 10 mm optical path, 350 µL nominal capacity and a narrow 1 mm sample region. This Standard 80 adhesive-bonded option uses a Two-Way Light layout and includes a closure. Sold as 1 cuvette per listed price unit.

In Stock

SKU: C102SS21 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C102SS21 is a quartz micro cuvette that combines a 10 mm optical path with a 350 µL nominal capacity in a compact body. Its 1 mm sample region is useful when you need a small illuminated section for transmission work, and the included closure supports routine handling of small sample volumes. This listed option is sold as 1 cuvette per price unit.

Path Length: 10 mm
Sample Volume (Nominal): 350 µL
Closure Type: Stopper

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Optical Window Dimensions	1 mm
Sample Volume (Nominal)	350 µL
External Dimensions	12.5 × 12.5 × 45 mm
Uncapped Cell Dimensions	12.5 × 12.5 × 45 mm
Overall Height without Closure	45 mm
External Dimensions Scope	Uncapped Cell
Base Dimensions	12.5 × 12.5 mm
Material	Quartz
Closure Type	Stopper
Closure Included	Yes
Fabrication Method	Standard 80
Detection Channel Width	1 mm

Choose this option

Choose C102SS21 when your method needs a 10 mm transmission path in a smaller quartz cell, and your sample routine suits an Standard 80 adhesive-bonded construction. The 350 µL nominal capacity helps you plan limited-volume measurements, while the 1 mm sample region is worth checking if your beam footprint is narrow and placement matters.

What makes this option different

10 mm optical path in a micro cuvette format for direct transmission measurements.
350 µL nominal capacity for small-volume sample handling.
1 mm sample region to consider when matching the beam to the illuminated area.
Closure included with the cuvette for this listed sale unit.

Using this cell

Fill the cell so the illuminated sample region is covered during measurement, then keep the same orientation for blank and sample runs. With a narrow sample region, introduce the liquid carefully and check for bubbles or residue on the optical faces before reading.

The stated 350 µL is the nominal capacity of the cell. It should not be treated as the minimum working fill for every instrument setup.

First-use check

Inspect the cell and closure for shipping damage, dust or residue.
Place the empty cell in the holder and check that it seats cleanly.
Run a blank first to confirm stable positioning and full beam coverage through the sample region.

Fit and optical alignment

The uncapped cell body is listed as 12.5 × 12.5 × 45 mm. Use those body dimensions to review holder seating and compartment clearance, and allow extra space above the rim for the fitted closure.

Z Height is not specified for this SKU. If your instrument has a fixed beam center or a holder with tight vertical alignment requirements, check that separately rather than using the overall body height as a beam-height value.

The Two-Way Light layout is for transmission through the opposing optical faces. The 1 mm sample region helps you judge beam placement, but it is not a substitute for beam-center alignment data.

Solvents and cleaning

Standard 80 adhesive-bonded quartz is generally chosen for routine water-based samples and buffers at room temperature. Avoid organic sample solvents and organic cleaning agents with this construction. If your method depends on organic-solvent use, a different fabrication route is usually the better starting point.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the exterior optical faces gently with non-abrasive optical tissue.

Included with this option

1 micro cuvette, with closure included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

If you need a different path length, body size, capacity, window arrangement, Z Height or closure style, send your drawing or labelled sketch with holder details, wavelength range and sample conditions. MQ can review custom JGS1 quartz projects separately from the listed SKU. Discuss your requirements and quote part number C102SS21.
