(C104SS27) Quartz Micro Cuvette, 10 mm Path, 1.4 mL

Weight	30 g

SKU: C104SS27

Original price was: $132.00.Current price is: $119.00.

In Stock

C104SS27 is a JGS1 quartz micro cuvette for fluorescence spectroscopy with a 10 mm optical path, Four-Way Light access and 1400 µL nominal capacity. This version uses a 4 mm sample-region width in a compact stoppered format, giving the broadest stated sample region in this set together with the largest nominal capacity. Sold per piece as 1 cuvette, with a closure included.

In Stock

SKU: C104SS27 Categories: Cuvettes, Products, Quartz Fluorescence Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C104SS27 is a stoppered JGS1 quartz micro cuvette for fluorescence spectroscopy when you need a 10 mm path in a compact closed cell. It combines Four-Way Light geometry with a 1400 µL nominal capacity and a 4 mm sample-region width, making it the roomiest option of these related channel-width variants while keeping the same compact cuvette footprint. This listing is sold as 1 cuvette, with a closure included.

Path Length: 10 mm
Sample Volume (Nominal): 1.4 mL
Closure Type: Stopper

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	Fluorescence Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Four-Way Light
Optical Window Dimensions	4 mm
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	1.4 mL
External Dimensions	12.5 × 12.5 × 45 mm
Base Dimensions	12.5 × 12.5 mm
Material	Quartz
Material Grade	JGS1
Closure Type	Stopper
Closure Included	Yes
Fabrication Method	Standard 80
Detection Channel Width	4 mm

Choose this option

Choose C104SS27 when you want a 10 mm fluorescence cuvette with optical access from multiple sides and a broader stated sample region than the narrower versions in the same family. The 4 mm sample-region width and 1400 µL nominal capacity are useful when your method benefits from a more generous filled measurement zone in a stoppered micro-cuvette format.

What makes this option different

10 mm optical path for fluorescence methods set up around this standard path length.
Four-Way Light geometry for optical access from multiple sides of the cuvette body.
1400 µL nominal capacity with a 4 mm sample-region width for the broadest stated illuminated sample region of these related options.
JGS1 quartz body in a 12.5 × 12.5 mm base format, sold as 1 cuvette with closure.

Using this cell

Fill the cell so the optical path passes through a continuous, bubble-free liquid region. The 1400 µL figure is the nominal capacity of the cell, not a minimum working volume, so actual fill level should be checked against your beam position and the way you orient the cuvette in use.

Seat the closure gently after filling and keep the optical faces clean and dry. For repeatable fluorescence measurements, keep the same orientation for blanks and samples so the same faces and sample region stay aligned with your instrument.

First-use check

Inspect the optical faces, edges and top opening before use. Rinse with a suitable mild liquid for your method, run a blank in the intended orientation, and confirm that the beam crosses a clean, fully filled section without visible bubbles.

Fit and optical alignment

The stated external dimensions are 12.5 × 12.5 × 45 mm, with a 12.5 × 12.5 mm base. This helps with holder footprint and general clearance checks, but the available data do not establish whether the 45 mm dimension should be treated as body-only or closure-inclusive.

Z Height is not listed for this SKU, so beam-center fit should be checked against your instrument requirement rather than assumed from the outer dimensions. The stated 4 mm sample-region width is relevant if your beam footprint or observation geometry needs a broader filled region than the tighter channel options.

Solvents and cleaning

This cuvette uses adhesive-bonded quartz construction and is listed under Standard 80. This construction is better suited to routine room-temperature water-based samples and buffers than to organic-solvent workflows. Avoid organic sample solvents and organic cleaning agents with this type of assembly.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe optical faces gently with non-abrasive optical tissue. Broader chemical compatibility limits for the full assembly are not established here for this SKU.

Included with this option

Supplied as 1 quartz micro cuvette. A closure is included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz production for changes to dimensions, optical path length, sample volume, optical windows, Z Height, closures and related tolerances. Send a dimensioned drawing or labelled sketch, together with holder details, sample conditions and target quantity. Discuss your requirements and quote part number C104SS27.
