(C102CS22) Quartz Micro Cuvette, 10 mm Path, 350 µL

Weight	30 g

SKU: C102CS22

Original price was: $76.00.Current price is: $69.00.

In Stock

C102CS22 is a JGS3 quartz micro cuvette with a 10 mm optical path, Two-Way Light layout and 350 µL nominal capacity for infrared spectroscopy and visible absorbance work. This version uses a 1 mm sample-region slit format and includes a PTFE lid. Supplied as 1 cuvette.

In Stock

SKU: C102CS22 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C102CS22 is a JGS3 quartz micro cuvette for infrared spectroscopy and visible absorbance work where you need a standard 10 mm path in a compact body. It combines a Two-Way Light layout, a 350 µL nominal capacity and a PTFE lid, while the 1 mm sample-region slit format helps you judge whether your beam footprint and holder geometry suit this cell. The listed MQ sale unit is one cuvette.

Path Length: 10 mm
Sample Volume (Nominal): 350 µL
Closure Type: Lid

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	Infrared Spectroscopy; Visible Absorbance Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Optical Window Dimensions	1 mm
Wavelength Range — Lower Limit	260 nm
Wavelength Range — Upper Limit	3500 nm
Sample Volume (Nominal)	350 µL
External Dimensions	12.5 × 12.5 × 45 mm
Cell Body Dimensions	12.5 × 12.5 × 45 mm
Uncapped Cell Dimensions	12.5 × 12.5 × 45 mm
External Dimensions Scope	Uncapped Cell
Material	Quartz
Material Grade	JGS3
Closure Type	Lid
Closure Material	PTFE
Closure Included	Yes
Fabrication Method	Standard 80
Detection Channel Width	1 mm

Choose this option

Choose C102CS22 when your method needs a 10 mm path micro cuvette with a modest nominal volume and covered top access. It is particularly useful when your setup can work with a narrow 1 mm sample-region format and when you need one cell rather than a supplier pack configuration.

What makes this option different

10 mm optical path: keeps the familiar 1 cm path in a compact micro cuvette body.
JGS3 quartz body: suited to the stated infrared and visible absorbance use range for this model.
1 mm sample-region slit format: makes beam footprint and alignment more important than with a wider sample region.
350 µL nominal capacity: supports small-volume work without changing to a shorter optical path.
PTFE lid included: provides covered handling at the top of the cell.

Using this cell

Fill the cell so the liquid fully covers the illuminated sample region, then check for bubbles before measurement. Keep the same orientation for blank and sample runs, and handle the cuvette by the non-optical surfaces where possible.

The PTFE lid is included for covered use, but this page does not define a sealed, pressure-rated or leak-tested assembly. The 350 µL value is the nominal capacity, not a minimum working volume, so establish your working fill in your own method.

First-use check

Inspect the windows, top opening and interior for dust, residue or handling marks.
Place the cell in the intended holder and confirm that it seats cleanly without forcing the body.
Run a blank at your working wavelength and fill level, then confirm that the sample covers the beam cleanly and the lid sits as expected for your handling routine.

Fit and optical alignment

The uncapped cell body measures 12.5 × 12.5 × 45 mm. Use these body dimensions to check holder seating, opening size and surrounding clearance, especially if your instrument has limited space above the cell position.

Z Height is not stated for this item, so instrument compatibility should not be assumed from outer size alone. The 1 mm sample-region format also means beam position and footprint should be checked carefully before ordering.

Solvents and cleaning

Standard 80 is an adhesive-bonded quartz construction that is commonly selected for routine room-temperature water-based samples and buffers. Avoid organic sample solvents and organic cleaning agents unless you have checked the full sample and cleaning conditions for all wetted parts, including the PTFE lid. If your method depends on organic solvents, ask about a more suitable Sintered or Molded construction.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the optical faces gently with non-abrasive optical tissue.

Included with this option

Supplied as 1 micro cuvette with a PTFE lid and storage box.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We can review changes to dimensions, path length, sample volume, closures and fabrication for related quartz micro cuvettes. Send your holder details or drawing, the beam geometry that matters in your instrument, your wavelength range and your sample conditions. Discuss your requirements and quote part number C102CS22.
