(C104CD8) Quartz Ultra-Micro Cuvette, 10 mm Path, 100 µL

Weight	30 g

SKU: C104CD8

Original price was: $223.00.Current price is: $201.00.

In Stock

C104CD8 is a JGS1 quartz ultra-micro cuvette for fluorescence spectroscopy with a 10 mm optical path, Four-Way Light access and 100 µL nominal capacity. Its open-top body and 1 mm sample-region width suit careful top filling where beam placement and sample coverage need close attention. Supplied as 1 cuvette.

In Stock

SKU: C104CD8 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C104CD8 is a JGS1 quartz ultra-micro cuvette for fluorescence spectroscopy with a 10 mm optical path, Four-Way Light access and a 100 µL nominal capacity. This open-top version also uses a 1 mm sample-region width, which makes filling practice and beam placement an important part of setup. Supplied as 1 cuvette.

Path Length: 10 mm
Sample Volume (Nominal): 100 µL
Opening Configuration: Open Top (Cell Body)

Selection Specifications

Product Kind	Cuvette
Cell Type	Ultra-Micro Cuvette
Measurement Mode	Fluorescence Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Four-Way Light
Optical Window Dimensions	1 mm
Sample Volume (Nominal)	100 µL
Material	Quartz
Material Grade	JGS1
Opening Configuration	Open Top (Cell Body)
Detection Channel Width	1 mm

Choose this option

Choose C104CD8 when you need a small-volume quartz cell with a full 10 mm path and direct top access for pipetting. The narrow 1 mm sample region is a key point for this version: it helps define the measurement area, but it also means your filling method, beam position and holder alignment need to suit this geometry.

What makes this option different

10 mm optical path in an ultra-micro cuvette format.
100 µL nominal capacity for small-volume sample loading.
Four-Way Light configuration for multi-side optical access in supported fluorescence setups.
1 mm sample-region width for methods that require this narrow measurement geometry.
Open-top cell body for direct pipette filling and visual checking during loading.
JGS1 quartz material for quartz-cell use where this grade is specified.

Using this cell

Fill the cell from the top and introduce enough sample to cover the illuminated region without trapping bubbles. With a narrow 1 mm sample region, careful pipetting and consistent loading practice are especially important. Keep the optical faces clean and free from droplets or residue before measurement.

Use the same seating direction for blank and sample measurements. The 100 µL figure is the nominal capacity of the cell and should not be treated as a minimum working volume.

First-use check

Inspect the optical faces for chips, dust or handling marks.
Rinse with a suitable liquid for your method.
Place the cell in the holder and confirm stable seating.
Run a blank and check that the filled sample region fully covers the beam.

Fit and optical alignment

Check the holder, sample compartment and beam position before ordering. In this format, matching the beam footprint to the sample region matters, and no released customer-fit value for Z Height is available here. Instrument fit should therefore be checked from your actual holder geometry and beam location.

If your setup has limited clearance or a fixed beam height, send the holder model or a dimensioned sketch for review before ordering.

Solvents and cleaning

Quartz is the cell material, but chemical compatibility for the complete selected assembly is not specified here with concentration, temperature or contact-time limits. If your method uses aggressive reagents or dedicated cleaning solvents, check the exact conditions before use.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning. For general care guidance, see https://machinedquartz.com/fabrication-method-of-cuvettes/.

Included with this option

Supplied as 1 cuvette. A closure or additional accessories are not listed here for this option.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz production for changes involving dimensions, optical path length, sample volume, optical windows or Z Height, closures and fabrication requirements. Send a dimensioned drawing or labelled sketch, together with holder details, sample conditions and your target quantity. Prototype batches typically involve 2–4 cells; feasibility, final specifications, price and production time are confirmed in the project quotation. https://machinedquartz.com/contact/ and quote part number C104CD8.
