(C104CS96) Quartz Ultra-Micro Cuvette, 10 mm Path, 200 µL

Weight	30 g

SKU: C104CS96

Original price was: $156.00.Current price is: $141.00.

In Stock

C104CS96 is a JGS1 quartz ultra-micro cuvette with a 10 mm optical path, 200 µL nominal capacity and Four-Way Light geometry for fluorescence spectroscopy. Its open-top body gives direct access for pipette loading and liquid-level inspection. Supplied as 1 cuvette.

In Stock

SKU: C104CS96 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C104CS96 is a JGS1 quartz ultra-micro cuvette for fluorescence spectroscopy when you want a 10 mm optical path with a modest sample charge and optical access from multiple sides. This version pairs a 200 µL nominal capacity with Four-Way Light geometry and an open-top body, making it suitable for direct filling and routine small-volume handling at the bench.

The larger nominal volume in this ultra-micro series gives you more fill range than the lower-capacity versions while keeping the same basic path length and open-top handling style. That makes it a practical option when your method still uses a small cuvette format but benefits from a little more room in the sample chamber.

Path Length: 10 mm
Sample Volume (Nominal): 200 µL
Opening Configuration: Open Top (Cell Body)

Selection Specifications

Product Kind	Cuvette
Cell Type	Ultra-Micro Cuvette
Measurement Mode	Fluorescence Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Four-Way Light
Sample Volume (Nominal)	200 µL
Material	Quartz
Material Grade	JGS1
Opening Configuration	Open Top (Cell Body)

Choose this option

Choose C104CS96 when you need a single ultra-micro quartz cuvette with a 10 mm path, Four-Way Light optical access and a 200 µL nominal capacity. The open top suits direct liquid loading, while the four-side optical layout is intended for fluorescence setups that need side access around the sample region.

What makes this option different

10 mm optical path for methods built around this stated path length.
200 µL nominal capacity for small-volume work with more nominal fill than the lower-capacity versions in this series.
Four-Way Light geometry for optical access from four sides.
Open-top body for direct pipette loading without a fixed closure over the sample opening.
JGS1 quartz material for fluorescence spectroscopy use.

Using this cell

Load the sample from the top and fill carefully so the illuminated sample region is covered during measurement. The open body makes it easy to inspect the liquid level before insertion, but it should be handled as an open laboratory cell rather than a sealed vessel.

Use the same seating direction for blank and sample runs, and avoid bubbles, droplets or residue on the optical faces. The 200 µL value is the nominal cell capacity for this option; it does not define a minimum working volume.

First-use check

Inspect the optical faces for dust, fingerprints or shipping residue.
Test the empty fit in the holder before filling.
Run a suitable blank and confirm that the beam passes through a fully covered sample region.
Keep the insertion orientation consistent between blank and sample.

Fit and optical alignment

Check the holder opening, available clearance and instrument beam position before ordering. Four-Way Light describes the supported optical access category, but holder fit and beam placement still need to match the usable sample region in your own setup.

If your instrument has a fixed beam height or a tight micro-cell holder, please verify the geometry against your fixture rather than assuming fit from path length or nominal volume. A released Z Height specification is not provided here for customer use.

Solvents and cleaning

This cuvette is made from quartz, but the exact chemical limits for this selected assembly are not established here. If your method uses aggressive chemicals, long contact times or heated cleaning, please check the exact sample and cleaning conditions before use.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning. For routine care, rinse promptly after use and wipe the exterior optical faces gently with non-abrasive optical tissue. For fabrication background and selection guidance, see MQ Cuvette Fabrication Glossary.

Included with this option

Supplied as 1 cuvette. No closure or additional accessory is specified for this listing.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We can review custom JGS1 quartz versions related to dimensions, optical path length, sample volume, window arrangement, Z Height, closures or fabrication needs. Send a labelled drawing or holder information together with the dimensions and tolerances that matter to your setup. Custom feasibility, quantity, price and production time are confirmed separately for the project. To discuss a custom version, use Discuss your requirements and quote part number C104CS96.
