(C202CE1) Quartz Large-Window Cuvette, 10 mm Path, 7 mL

Weight	30 g

SKU: C202CE1

Original price was: $104.00.Current price is: $94.00.

In Stock

C202CE1 is a JGS1 quartz large-window cuvette for UV/Vis measurements from 200 to 2500 nm, with a 10 mm optical path and 7 mL nominal capacity. Its open-top body gives direct access for filling and rinsing, and a cover is included for covered handling between steps. Priced and sold per 1 cuvette.

In Stock

SKU: C202CE1 Categories: Cuvettes, Products, Quartz Large Window Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C202CE1 is a JGS1 quartz large-window cuvette for UV/Vis work with a 10 mm optical path and 7 mL nominal capacity. The open-top body gives direct top access for loading, rinsing and visual checks, while the large rectangular format suits setups built around a full-size transmission cell rather than a micro-volume chamber.

Path Length: 10 mm
Sample Volume (Nominal): 7 mL
Opening Configuration: Open Top

Selection Specifications

Product Kind	Cuvette
Cell Type	Large-Window Cuvette
Measurement Mode	UV/Vis Spectroscopy
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	7 mL
External Dimensions	22.5 × 12.5 × 45 mm
Cell Body Dimensions	22.5 × 12.5 × 45 mm
External Dimensions Scope	Body Only
Material	Quartz
Material Grade	JGS1
Closure Type	Lid
Closure Included	Yes
Opening Configuration	Open Top

Choose this option

Choose C202CE1 when your method uses a straight 10 mm transmission path and you want direct top filling in a larger sample chamber. This format is useful when you need room for routine pipetting, blank preparation and rinse steps, and when your holder is arranged for a rectangular cuvette body rather than a flow cell or demountable assembly.

What makes this option different

10 mm optical path for UV/Vis methods that use a defined straight-through transmission distance.
Two-Way Light configuration for measurement across the main optical axis of the cell.
Open-top access for direct filling, emptying and rinsing from above.
7 mL nominal capacity in a full-size sample chamber, with more room for routine liquid handling than a micro cell format.
22.5 × 12.5 × 45 mm body-only size to check against holder space and surrounding clearance.
Cover included for covered handling between preparation steps, without treating it as a pressure or sealing feature.
Supplier-labelled joining technology is noted, but the joining method itself is not specified for this SKU, so cleaning and solvent choice should be judged with the complete application in mind.

Using this cell

Fill the cell from the top and orient it consistently so the beam passes through the same faces for blank and sample readings. The wide rectangular body makes it practical for routine transfer by pipette and for visual inspection of the liquid before measurement.

The 7 mL figure is the nominal cell capacity, not a minimum working volume. If your method depends on a defined beam height or a reduced fill level, check that the illuminated region remains fully covered in your actual holder.

First-use check

Inspect the optical faces, top opening and edges for chips, dust or residue.
Place the cell in the holder and verify stable seating before filling.
Run a blank in the same orientation you plan to use for sample measurements.
Check for visible bubbles or droplets on the transmission faces before reading.

Fit and optical alignment

The stated 22.5 × 12.5 × 45 mm dimensions apply to the body only. Check assembled top clearance separately if your holder, cover use or loading workflow depends on the height with the cover in place.

Z Height is not stated for this SKU. If your instrument has a fixed beam position or a tightly constrained holder, compare the beam position with your current cell or holder dimensions before ordering.

Solvents and cleaning

This quartz cell is intended for UV/Vis sample handling and measurement. For general fabrication background, see the MQ fabrication guide.

The joining method is not specified for this SKU, so do not assume a particular solvent tolerance from a fabrication grade. Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and clean the optical faces gently with suitable laboratory wipes and rinse solvents appropriate to your procedure.

Included with this option

Priced and sold per 1 cuvette. A closure is included. Other package contents are not specified for this SKU.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz projects for changes to dimensions, optical path length, sample volume, optical windows or Z Height, closures and related geometry. If you need a different fit, send your holder details or a labelled drawing through the contact page and quote C202CE1.
