(C202CR8) Quartz Large-Window Cuvette, 10 mm Path, 7 mL

Weight	100 g

SKU: C202CR8

Original price was: $86.00.Current price is: $78.00.

In Stock

C202CR8 is a JGS1 quartz large-window cuvette for UV/Vis spectroscopy with a 10 mm optical path and 7 mL nominal capacity. Its larger optical body format gives more room for filling and visual checking than a compact cell while keeping a standard 10 mm path. Sold as 1 cuvette per price unit, with lid and box included.

In Stock

SKU: C202CR8 Categories: Cuvettes, Products, Quartz Large Window Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C202CR8 is a JGS1 quartz large-window cuvette for UV/Vis methods that use a 10 mm optical path but need a roomier sample chamber. Its 7 mL nominal capacity and broader body format can make filling, blanking and visual inspection more straightforward, especially when you want more clearance around the liquid surface than in a compact routine cell. This option is sold as 1 cuvette, and the pictured source indicates a lid and storage box are included.

Path Length: 10 mm
Sample Volume (Nominal): 7 mL
Closure Type: Lid

Selection Specifications

Product Kind	Cuvette
Cell Type	Large-Window Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	7 mL
External Dimensions	22.5 × 12.5 × 45 mm
Cell Body Dimensions	22.5 × 12.5 × 45 mm
External Dimensions Scope	Body Only
Material	Quartz
Material Grade	JGS1
Closure Type	Lid
Closure Included	Yes

Choose this option

Choose C202CR8 when your method is built around a standard 10 mm path and you want that path in a larger quartz body rather than a narrow small-volume format. The large-window layout is useful when you need easier top access for filling and a wider viewing area across the sample region, while the 7 mL nominal capacity suits methods that are prepared around a larger fill volume.

What makes this option different

10 mm optical path for standard UV/Vis measurement geometry.
Large-window cuvette body that gives a broader optical face and easier visual access to the sample region.
7 mL nominal capacity for methods that use a larger prepared sample volume.
JGS1 quartz construction for UV/Vis use across the stated 200–2500 nm range.
Fused integrated construction is stated for this large-window body format.
Body dimensions are 22.5 × 12.5 × 45 mm, measured on the cuvette body only.
Sold as 1 cuvette per listed price unit; lid and box are included.

Using this cell

Fill the cuvette from the top and make sure the liquid fully covers the beam during measurement. Before reading, check the optical area for bubbles, droplets or particles that sit in the light path, and keep the same orientation for blank and sample runs.

The larger body format gives more space above the sample region for routine filling and handling, but the nominal capacity is not a minimum working volume. If your method runs close to a low fill level or depends on a fixed beam height, confirm that the liquid level and beam position match your setup before use.

First-use check

Inspect the optical faces for chips, scratches, dust or residue.
Place the empty cuvette in your holder to check seating and top clearance with the lid arrangement you plan to use.
After filling, confirm that the beam area is fully covered and visually free of bubbles.

Fit and optical alignment

The stated 22.5 × 12.5 × 45 mm dimensions apply to the body only. Allow extra clearance above the cuvette for the lid and for comfortable handling in the instrument compartment or holder.

This cell uses a 10 mm path, but the Z Height is not stated here. If your instrument, thermostat block or accessory holder depends on a specific beam-center height, check that point separately rather than relying on body size alone.

Solvents and cleaning

This cuvette uses JGS1 quartz with fused integrated construction. For general background on cuvette construction choices and how they affect sample and cleaning selection, see Compare fabrication methods.

The chemical limits of this exact assembly are not established here, so choose sample and cleaning conditions with care. Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the optical faces gently with non-abrasive optical tissue.

Included with this option

1 cuvette per listed price unit. Closure included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz versions for changes to dimensions, optical path length, sample volume, optical access, Z Height, closures and tolerance requirements. Send a dimensioned drawing or labelled sketch together with holder details, wavelength range, sample conditions and required quantity. Prototype batches typically involve 2–4 cells; feasibility, final specifications, price and production time are confirmed in the project quotation. Discuss your requirements and reference C202CR8.
