(C37.52CR) Quartz Large-Window Cuvette, 37.5 mm Path, 5.4 mL

Weight100 g
SKU: C37.52CR

Original price was: $90.00.Current price is: $81.00.

In Stock

C37.52CR is a JGS1 quartz large-window cuvette for UV/Vis work with a 37.5 mm optical path, Two-Way Light layout and 5.4 mL nominal capacity. Its open-top body gives direct access to the long, narrow sample chamber for filling, rinsing and visual checks. Sold per 1 cuvette.

In Stock
Add to Wishlist
Add to Wishlist
SKU: C37.52CR Categories: , , Brand:
Shipping and order support
  • Worldwide delivery to door service, hassle free shipping
  • Contact us for quotation of bulk purchase discount
  • Custom design. Send us graphic drawing for solution
  • POs for Academics. Pay after delivery.
  • Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C37.52CR is a JGS1 quartz large-window cuvette for UV/Vis spectroscopy across the stated 200–2500 nm range. It combines a 37.5 mm optical path with a 5.4 mL nominal capacity in an open-top body, so you can work with a longer transmission length while keeping direct access to the sample chamber.

Path Length
37.5 mm
Sample Volume (Nominal)
5.4 mL
Opening Configuration
Open Top (Cell Body)

Selection Specifications

Product KindCuvette
Cell TypeLarge-Window Cuvette
Measurement ModeUV/Vis Spectroscopy
Path Length37.5 mm
Light Transmission ConfigurationTwo-Way Light
Wavelength Range — Lower Limit200 nm
Wavelength Range — Upper Limit2500 nm
Sample Volume (Nominal)5.4 mL
External Dimensions40 × 8 × 35 mm
Uncapped Cell Dimensions40 × 8 × 35 mm
Overall Height without Closure35 mm
External Dimensions ScopeUncapped Cell
Body Height35 mm
Internal Dimensions37.5 × 5.5 × 33 mm
MaterialQuartz
Material GradeJGS1
Opening ConfigurationOpen Top (Cell Body)

Choose this option

Choose C37.52CR when your method is specified around a 37.5 mm path and you want a straightforward transmission cell rather than a closed or flow-through format. The internal dimensions of 37.5 × 5.5 × 33 mm create a long, slim sample region, which is useful when the optical path matters as much as the chamber shape and access from above.

What makes this option different

  • 37.5 mm optical path for methods written around this transmission length.
  • 5.4 mL nominal capacity in a long, narrow internal chamber.
  • Open-top body for direct filling, emptying and rinsing access.
  • Two-Way Light layout for transmission measurements through opposite optical faces.

Using this cell

Fill the cell from the open top and make sure the liquid covers the beam during measurement. Before reading, remove visible bubbles from the optical region and keep the same orientation for blank and sample if your method depends on repeatable positioning.

The stated 5.4 mL is the nominal cell capacity, not a minimum working volume. If you plan to use less than the nominal fill, check that the liquid level still covers the beam in your instrument.

First-use check

Inspect the optical faces on arrival, rinse with a cleaning liquid suitable for your method, and run a blank before sample measurements. Confirm that the beam passes through a fully covered, bubble-free sample region.

Fit and optical alignment

The listed outer dimensions of 40 × 8 × 35 mm apply to the uncapped cell body. Use these dimensions to check holder width, compartment clearance and handling space, especially where the body depth is limited.

Z Height is not listed for this SKU. If your holder or spectrometer depends on a defined beam-center height, please confirm that separately rather than assuming fit from the body size alone.

Solvents and cleaning

This cuvette is made from JGS1 quartz. For general fabrication guidance across cuvette types, see Compare fabrication options.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the optical faces with non-abrasive optical tissue only. If your samples or cleaning routine involve aggressive chemicals or prolonged contact conditions, please check suitability before ordering.

Included with this option

1 cuvette per listed price unit. If you need a supplied closure or other accessory, contact us before ordering.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We also review custom JGS1 quartz cuvette requests involving path length, chamber dimensions, sample volume, openings and holder-related fit. Send your drawing or labelled sketch together with holder details, wavelength range and sample conditions via our contact page, and mention part number C37.52CR.

Additional information

Weight100 g
