(C502CR5) Quartz Large-Window Cuvette, 10 mm Path, 17.5 mL

Weight	100 g

SKU: C502CR5

Original price was: $142.00.Current price is: $128.00.

In Stock

C502CR5 is a JGS1 quartz large-window cuvette with a 10 mm optical path, Two-Way Light transmission and a 17.5 mL nominal capacity for UV/Vis measurements from 200 to 2500 nm. The open-top body gives direct access to a larger sample chamber, and a closure is included. The listed price is for 1 cuvette.

In Stock

SKU: C502CR5 Categories: Cuvettes, Products, Quartz Large Window Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C502CR5 is a JGS1 quartz large-window cuvette for UV/Vis measurements from 200 to 2500 nm. It uses a 10 mm optical path in a larger-body format with 17.5 mL nominal capacity, giving you a standard transmission length together with a broader sample chamber and direct top access. This listed option includes a closure, and the listed price is for 1 cuvette.

Path Length: 10 mm
Sample Volume (Nominal): 17.5 mL
Opening Configuration: Open Top

Selection Specifications

Product Kind	Cuvette
Cell Type	Large-Window Cuvette
Measurement Mode	UV/Vis Spectroscopy
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	17.5 mL
External Dimensions	52.5 × 12.5 × 45 mm
Body Height	45 mm
Base Dimensions	52.5 × 12.5 mm
Material	Quartz
Material Grade	JGS1
Closure Included	Yes
Opening Configuration	Open Top

Choose this option

Choose C502CR5 when your method is built around a 10 mm path but a narrow low-volume cuvette body is not the best fit for your handling routine. The larger chamber and open top make filling, rinsing and general bench use more straightforward where extra space in the cell is useful.

What makes this option different

10 mm optical path for standard transmission measurements.
17.5 mL nominal capacity in a large-window format with more chamber volume than a compact cell body.
Open-top chamber with closure included for direct access to the sample region.
52.5 × 12.5 × 45 mm outer dimensions that make holder fit and beam clearance important checks.

Using this cell

Load the sample from the top and make sure the liquid level fully covers the optical path during measurement. Remove bubbles from the beam area before reading, and keep the same orientation for blank and sample measurements when your method depends on consistent positioning.

The supplied closure is part of this listed option for normal laboratory handling. No pressure rating or sealing test is stated for this SKU, so it should not be treated as a pressure-tight or leak-qualified assembly.

First-use check

Before first use, inspect the optical faces, top opening and closure, then rinse the chamber with your measurement solvent or another suitable cleaning solvent. Run a blank and confirm that the cell seats properly in your holder and that the beam passes through the intended optical region when filled.

Fit and optical alignment

This cuvette uses a Two-Way Light layout through two opposite optical faces. Its external dimensions are 52.5 × 12.5 × 45 mm, so the body geometry may matter as much as the path length if your holder was designed for smaller or differently shaped cuvettes.

Z Height is not specified in the accepted record. If your instrument requires a defined beam center height, please verify that geometry before ordering.

Solvents and cleaning

Compare fabrication options for your sample and cleaning routine. The detailed chemical limits for this exact SKU are not specified here, so if your work involves aggressive chemicals or demanding cleaning conditions, please check suitability for the intended liquid and cleaning method before purchase.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the optical faces gently with non-abrasive optical tissue or another lint-free wipe suitable for optical surfaces.

Included with this option

1 cuvette per listed price unit. Closure included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz production for requirements involving dimensions, optical path length, sample volume, optical windows or Z Height, closures and connections, fabrication and tolerances. Send a dimensioned drawing or labelled sketch and identify the dimensions and tolerances that are critical to your application. Prototype batches typically involve 2–4 cells; the final quantity, feasibility, specifications, price and production time are confirmed in the project quotation. Modified designs and prototype batches are quoted separately from the listed SKU. Discuss your requirements and quote part number C502CR5.
