Quartz 6mm Standard Cuvette, 0.54ml, Standard 80, Two-way Light, No Cap, 1pc/ea, C062CS

Weight	30 g

SKU: C062CS

C062CS Quartz 6mm Two-Way Light Colorimetric Cuvette 0.54ml Standard 80

Original price was: $29.00.Current price is: $27.00.

In Stock

Quartz 6mm colorimetric cuvette, 0.54ml, Standard 80 (>80% transmittance). Two-Way Light. No Cap. 190–2500 nm. SKU: C062CS.

In Stock

SKU: C062CS Categories: Cuvettes, Products, Quartz Colorimetric Cuvettes Brand: MachinedQuartz

Worldwide Timed Dispatch Available

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Standard cuvettes ship in 3-5 days. Custom items 1-2 weeks.

Description

The C062CS is a quartz colorimetric cuvette with 6mm path length and two-way light optical configuration — two opposing faces are polished to optical grade for standard absorbance measurements. With a 0.54ml internal volume (7 × 6 × 29 mm chamber), this compact cell is designed for automated biochemical analyzers, clinical chemistry instruments, and colorimetric assay workflows. Fabricated using Standard 80 (>80% transmittance) — precision-glued quartz panels for reliable optical alignment. The open-top design (no cap) allows quick sample loading and easy cleaning between measurements.

Technical Specifications — Colorimetric Cuvette
Material	Quartz (JGS1)	SKU	C062CS
Path Length	6mm	Internal Volume	0.54ml
Optical Windows	2 (Two-Way Light)	Fabrication	Standard 80
Transmittance	>80%	Wavelength	190–2500 nm
Exterior Dimensions	8 × 6.3 × 30 mm	Interior Dimensions	7 × 6 × 29 mm
Closure	Open Top (No Cap)	Package	1pc/ea

Colorimetric & Analytical Applications

◆ Clinical Chemistry — enzymatic assays, metabolite quantification, and automated diagnostic tests on biochemical analyzers

◆ UV-Vis Absorbance — quantitative concentration, kinetics, and Beer–Lambert studies

◆ Water Quality — residual chlorine (DPD), COD, nitrate, phosphate, and heavy-metal colorimetric tests

◆ Protein Assays — Bradford, BCA, Lowry, and direct A280 measurements

◆ Enzyme Kinetics — real-time substrate conversion and inhibition studies

◆ Pharmaceutical QC — dissolution testing, drug concentration, and stability monitoring

◆ Food & Beverage — color index, additive quantification, and quality-control colorimetry

◆ Environmental Monitoring — turbidity, Hazen/APHA color, and dissolved-substance screening

Why Two-Way Light?

Two-way light cuvettes have two opposing faces polished to optical grade, providing a single well-defined beam path for standard absorbance measurements. This is the standard configuration for UV-Vis spectrophotometers and colorimeters, delivering clean baseline performance and maximum signal-to-noise ratio for quantitative colorimetric analysis.

Why Open Top?

The open-top design (no cap) allows quick sample loading and easy cleaning between measurements. PTFE is chemically inert and will not leach absorbing compounds into the sample. While not airtight, the cap reduces evaporation during short measurement cycles and protects the optical surfaces when the cuvette is stored.

Why Standard 80?

Standard 80 uses precision-applied optical adhesive to bond quartz panels, delivering >80% transmittance from 190–2500 nm. The glued construction provides excellent optical alignment at an economical price point. Best suited for aqueous colorimetric reagents and DPD-based water-quality tests where organic solvent resistance is not required.

Usage Tips

Rinse with a compatible solvent (e.g., deionized water or the measurement solvent) before first use to remove any residual particles.
Do not use abrasive materials or brushes on the polished optical faces — wipe gently with lens tissue.
Compatible with aqueous solutions only — avoid organic solvents, strong acids, and strong bases.
Store in the original protective case to prevent scratches on the optical windows.
For baseline correction, fill with your reference solvent and run a blank before sample measurements.

Custom Orders
Need a non-standard path length, volume, window configuration, or closure type? We manufacture quartz cuvettes to your exact specifications. Request a custom quote.

Disclaimer: Specifications are nominal values measured under standard laboratory conditions. Actual transmittance may vary slightly with wavelength and sample conditions. Images are representative; minor cosmetic variations between production batches are normal and do not affect optical performance.
