(MQQFC013) Quartz Rectangular Sample Cell, 10 mm Path, 10 mL, Open at Both Ends
$359.00
JGS1 quartz rectangular sample cell with a 10 mm optical path, Four-Way Light access and an open-at-both-ends body for custom filling, sealing or mounting arrangements. Its 10 mL nominal capacity and 10 × 10 × 100 mm internal sample region suit longer straight sample chambers built into a dedicated fixture. Sold as 1 piece.
Description
MQQFC013 is a JGS1 quartz rectangular sample cell for setups that need a 10 mm optical path in a long straight chamber with access through both ends. Its Four-Way Light layout, 10 mL nominal capacity and open body format make it useful when the cell is part of a custom assembly rather than a finished cuvette with a fixed cap or connector.
This item is the sample cell body itself. You can build the end support, sealing and filling approach around your own method, while keeping optical access available from the sides of the rectangular body.
- Path Length
- 10 mm
- Sample Volume (Nominal)
- 10 mL
- Opening Configuration
- Open at Both Ends
Selection Specifications
| Product Kind | Specialized Cell |
|---|---|
| Cell Type | Rectangular Sample Cell |
| Measurement Mode | Transmission Spectroscopy |
| Path Length | 10 mm |
| Light Transmission Configuration | Four-Way Light |
| Wavelength Range — Lower Limit | 200 nm |
| Wavelength Range — Upper Limit | 2500 nm |
| Sample Volume (Nominal) | 10 mL |
| External Dimensions | 13 × 13 × 100 mm |
| Body Height | 100 mm |
| Base Dimensions | 13 × 13 mm |
| Internal Dimensions | 10 × 10 × 100 mm |
| Material | Quartz |
| Material Grade | JGS1 |
| Opening Configuration | Open at Both Ends |
| Pack Quantity | 1 Piece |
Choose this option
Choose MQQFC013 when your setup needs a long rectangular quartz sample region with direct access from both ends and a standard 10 mm optical path. This format is useful when the holder, end treatment and sample handling are designed together, for example where you need to fill, retain or connect the sample chamber in your own fixture instead of relying on a preassembled cuvette format.
What makes this option different
- Open at both ends gives direct access to the full chamber length, so filling, draining, sealing or connecting the cell can be arranged around your own support hardware.
- 10 mm optical path suits methods and holders designed around that path length without moving to a narrower micro-volume geometry.
- Four-Way Light provides optical access from four sides of the rectangular body, which helps when your fixture needs side access around the sample region rather than a single fixed viewing direction.
- 10 mL nominal capacity is paired with a long 10 × 10 × 100 mm internal chamber, giving a straight sample region for setups that need more volume in an extended body.
- Powder-fused construction is the supplier’s construction term for this cell. In practical selection, it identifies this as a fused quartz body style for customers planning an open-ended assembly, while the sealing parts, fittings and final chemical exposure still need to be judged as a complete setup.
Structure and dimensions

Using this cell
Install the cell in a holder that supports the 13 × 13 mm outside body and defines how the two open ends are retained in use. Because the cell is supplied as an open sample body, the assembled fixture should also determine how liquid is introduced, held and removed.
When preparing a method, establish the filling routine, bubble removal and blank/sample orientation in the final assembly. Keep the outside optical faces clean and dry before measurement so residue or fingerprints do not sit in the beam path.
First-use check
- Inspect the optical faces, chamber edges and both open ends for chips, contamination or packing residue.
- Test the cell in your fixture with a blank to confirm support, alignment and sample retention.
- Before measurement, remove bubbles and wipe any external liquid film from the transmitting faces.
Fit and optical alignment
Use the external 13 × 13 × 100 mm body dimensions to check holder clearance. The listed 10 × 10 × 100 mm internal dimensions describe the chamber space, not the mounting envelope, so mechanical fit should be based on the outside body.
Z Height is not listed for this cell. If your instrument or holder depends on a defined beam-center height, check that from the actual mounting geometry rather than assuming it from the overall body height.

Solvents and cleaning
This cell body is JGS1 quartz. The supplier also identifies the construction as powder-fused, but the usable chemical range of your finished setup depends on the complete assembly, including any seals, supports or added end fittings.
Keep hydrofluoric acid away from quartz. Avoid hot strong alkalis and abrasive cleaning methods. Clean the optical faces gently with non-abrasive optical tissue and a suitable cleaning liquid for your procedure.
For background on MQ fabrication terms, see Fabrication Method of Cuvettes.
Included with this option
1 rectangular sample cell, SKU MQQFC013. The listed price is for one piece.
Availability and ordering
Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.
Discuss a custom version
We also coordinate custom JGS1 quartz versions for requirements involving path length, body size, chamber size, optical access and end arrangement. If your application needs a different envelope, beam position or holder interface, please send a drawing or sketch with the critical dimensions, sample conditions and required quantity.
Send a product-selection enquiry with SKU MQQFC013 and your fixture or application details.
Additional information
| Weight | 150 g |
|---|
