(MQQFC020) Quartz Rectangular Sample Cell, 15 mm Path, 12 mL, Open at Both Ends

Weight150 g
SKU: MQQFC020

$215.00

In Stock

MQQFC020 is a JGS1 quartz rectangular sample cell with a 15 mm optical path, 12 mL nominal capacity and Two-Way Light access. Its open-at-both-ends body provides a broad 20 × 15 × 40 mm chamber for custom holders or assemblies that define their own end support and sealing. Sold as 1 piece.

In Stock
Add to Wishlist
Add to Wishlist
Shipping and order support
  • Worldwide delivery to door service, hassle free shipping
  • Contact us for quotation of bulk purchase discount
  • Custom design. Send us graphic drawing for solution
  • POs for Academics. Pay after delivery.
  • Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

MQQFC020 is a JGS1 quartz rectangular sample cell with a 15 mm optical path and a 12 mL nominal capacity. The body is open at both ends and uses a Two-Way Light layout, with a broad rectangular chamber inside a larger rectangular outer envelope. This makes it a practical choice when your method needs a wider sample section than a narrow standard-format body and your holder already defines how the open ends will be supported.

Path Length
15 mm
Sample Volume (Nominal)
12 mL
Opening Configuration
Open at Both Ends

Selection Specifications

Product KindSpecialized Cell
Cell TypeRectangular Sample Cell
Measurement ModeTransmission Spectroscopy
Path Length15 mm
Light Transmission ConfigurationTwo-Way Light
Wavelength Range — Lower Limit200 nm
Wavelength Range — Upper Limit2500 nm
Sample Volume (Nominal)12 mL
External Dimensions40 × 27 × 40 mm
Body Height40 mm
Base Dimensions40 × 27 mm
Internal Dimensions20 × 15 × 40 mm
MaterialQuartz
Material GradeJGS1
Fabrication MethodStandard 80
Opening ConfigurationOpen at Both Ends
Pack Quantity1 Piece

Choose this option

Choose MQQFC020 when your setup calls for a 15 mm path and a relatively broad rectangular sample region. It suits custom fixtures where chamber width, outer body size and direct end access matter more than a capped cuvette format or integrated liquid connections.

View the English selection reference.

What makes this option different

  • 15 mm optical path: suited to methods built around a longer transmission distance through the sample.
  • Broad rectangular chamber: the 20 × 15 × 40 mm internal dimensions define a wider sample region than a narrow slit-style body.
  • Open at both ends: the cell is intended for user-defined support, filling and sealing rather than as a complete sealed assembly.
  • Larger outer envelope: the 40 × 27 × 40 mm body should be checked in full against holder clearance and clamping space.

Structure and dimensions

Product dimensions for checking holder clearance and sample access.
Product dimensions for checking holder clearance and sample access.Open image ↗

Using this cell

Install the cell so the beam crosses the 15 mm path through the transmitting faces, and keep that orientation consistent for blank and sample measurements. The 12 mL figure is the nominal chamber capacity, so the practical fill condition depends on the way the open ends are retained and sealed in your setup.

For liquid work, establish the filling, venting and bubble-control steps with the actual holder before routine use. Open-ended geometry can be useful in custom assemblies, but it does not by itself provide leak control, pressure handling or tubing connection.

First-use check

  1. Inspect the optical faces, chamber opening and end edges before mounting.
  2. Verify that the holder supports the body evenly without loading the transmitting faces.
  3. Run a blank with your actual sealing and filling method to check alignment, sample retention and bubble control.

Fit and optical alignment

Use the full 40 × 27 × 40 mm outer dimensions when checking mechanical fit. The internal 20 × 15 × 40 mm dimensions describe the chamber only, so they should not be treated as the holder opening or external clearance requirement.

Z Height is not specified for this SKU. If your instrument depends on a fixed beam-center height, confirm that dimension in the mounted arrangement before ordering for beam-height-sensitive work.

English selection reference
Selection reference ↗

Solvents and cleaning

This cell uses Standard 80 adhesive-bonded quartz construction. It is generally suited to routine room-temperature aqueous samples and buffers. Avoid organic samples and organic cleaning solvents on the bonded assembly.

Keep hydrofluoric acid away from quartz. Avoid hot strong alkalis and abrasive cleaning methods. Clean the optical faces gently with a suitable lint-free, non-abrasive wipe.

Included with this option

1 MQQFC020 rectangular sample cell. The listed price is for one cell.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz versions for changes to path length, chamber size, outer envelope, openings and holder-related geometry. If you need a different layout for the same general method, send a labelled drawing or sketch with the critical dimensions, sample conditions and holder constraints.

Send a product-selection enquiry with SKU MQQFC020 and your holder or application details.
