(C102SR19) Quartz Micro Cuvette, 10 mm Path, 350 µL

Weight	30 g

SKU: C102SR19

Original price was: $143.00.Current price is: $129.00.

In Stock

C102SR19 is a JGS1 quartz micro cuvette with a 10 mm optical path, 350 µL nominal capacity and a 1 mm sample region. Its fused integrated construction and stated 200–2500 nm range make it a compact option for UV/Vis transmission work, with a closure included. Sold as 1 cuvette per listed price unit.

In Stock

SKU: C102SR19 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C102SR19 is a JGS1 quartz micro cuvette for UV/Vis transmission work with a 10 mm optical path and 350 µL nominal capacity. It combines a compact body, a narrow 1 mm sample region and a stated 200–2500 nm range, which makes it useful when your method needs quartz transmission in a smaller cell rather than a larger standard format. This listed option is sold as 1 cuvette per price unit, with closure included.

Path Length: 10 mm
Sample Volume (Nominal): 350 µL
Closure Type: Stopper

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Optical Window Dimensions	1 mm
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	350 µL
External Dimensions	12.5 × 12.5 × 45 mm
Body Height	45 mm
Base Dimensions	12.5 × 12.5 mm
Material	Quartz
Material Grade	JGS1
Closure Type	Stopper
Closure Included	Yes
Detection Channel Width	1 mm

Choose this option

Choose C102SR19 when you need a 10 mm path length in a compact quartz micro cuvette and your method calls for the stated 200–2500 nm transmission range. The fused integrated construction is also a meaningful build choice for buyers comparing cell styles, while the 350 µL nominal capacity helps you plan small-volume measurements without moving to a wider body.

What makes this option different

JGS1 quartz with a stated 200–2500 nm range for UV/Vis transmission use.
10 mm optical path in a compact micro cuvette body.
350 µL nominal capacity with a 1 mm sample region for small-volume setups where beam placement matters.
Fused integrated construction with closure included for this sale unit.

Using this cell

Introduce the sample carefully so the illuminated region is fully covered and free of bubbles. Keep the same orientation between blank and sample runs, and keep the outer optical faces clean and dry before measurement.

The listed 350 µL is the nominal capacity of the cell. It does not define the minimum working fill needed for every spectrometer or holder arrangement.

First-use check

Inspect the cell and closure before use.
Place the empty cuvette in the holder to check seating and clearance.
Run a blank first and confirm that the beam passes cleanly through the intended sample region.

Fit and optical alignment

The external dimensions are 12.5 × 12.5 × 45 mm, with a 12.5 × 12.5 mm base. These dimensions help you check whether the cell will seat in your holder and whether there is enough clearance in the sample compartment.

Z Height is not specified for this SKU, so total height should not be treated as beam-center height. If your instrument has a fixed beam position or a micro-cell holder with tight vertical alignment requirements, check that point before ordering.

The Two-Way Light configuration is intended for transmission through the main opposing optical faces. The stated 1 mm sample region should be matched to the beam footprint in your setup.

Solvents and cleaning

Choose cleaning and sample conditions that are suitable for quartz micro cuvettes and for the complete wetted assembly. If your method depends on a defined solvent compatibility range, discuss the liquid, concentration, temperature and contact time before purchase, because detailed chemical limits are not established here.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning. For general build-style guidance, see Compare fabrication methods.

Included with this option

1 micro cuvette, with closure included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

If you need a different size, path length, capacity, window arrangement, Z Height or closure style, send a drawing or labelled sketch together with holder information, wavelength range and sample conditions. MQ can review custom JGS1 quartz projects separately from this listed SKU. Discuss your requirements and quote part number C102SR19.
