(C102SS17) Quartz Micro Cuvette, 10 mm Path, 1.05 mL

Weight	30 g

SKU: C102SS17

Original price was: $72.00.Current price is: $65.00.

In Stock

C102SS17 is a JGS1 quartz micro cuvette for UV/Vis work with a 10 mm optical path, Two-Way Light layout and 1.05 mL nominal capacity. Its compact 12.5 × 12.5 mm base and 3 mm sample-region width suit transmission measurements where holder space and beam size both need attention. Sold as 1 cuvette per price unit, with a closure included.

In Stock

SKU: C102SS17 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C102SS17 is a JGS1 quartz micro cuvette for UV/Vis spectroscopy with a 10 mm optical path in a compact 12.5 × 12.5 mm body format. Its 1.05 mL nominal capacity and 3 mm sample-region width make it useful when you need a standard transmission path length in a smaller cell and your beam is suited to a narrow measurement region. The closure is included, and the listed price is for 1 cuvette.

Path Length: 10 mm
Sample Volume (Nominal): 1.05 mL
Closure Type: Stopper

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Optical Window Dimensions	3 mm
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	1.05 mL
External Dimensions	12.5 × 12.5 × 45 mm
Base Dimensions	12.5 × 12.5 mm
Material	Quartz
Material Grade	JGS1
Closure Type	Stopper
Closure Included	Yes
Fabrication Method	Standard 80
Detection Channel Width	3 mm

Choose this option

Choose C102SS17 when your method needs a 10 mm path length but your holder or sample plan points to a micro cuvette rather than a larger standard cell. This option combines a compact square footprint with a defined 3 mm sample region, so it is best suited to straight-through UV/Vis measurements where beam placement, fill coverage and external clearance all matter.

What makes this option different

10 mm optical path for transmission methods built around the standard 10 mm light path.
1.05 mL nominal capacity in a micro cuvette body for small-format sample handling.
3 mm sample-region width for setups that suit a narrow illuminated region.
Closure included for covered filling and measurement, without implying a pressure-rated or leak-tested assembly.

Using this cell

Fill the cell so the beam passes through a fully covered liquid region, and keep the optical faces free of bubbles, droplets and residue. The 1.05 mL value is the nominal cuvette capacity, not a minimum working volume, so the actual fill needed for your method depends on your beam height and handling practice.

Use the same orientation for blank and sample measurements, and insert or remove the closure carefully to avoid disturbing the sample at the reading area. If your work involves inversion, transport after filling or other situations where leakage matters, check the complete assembly in your own conditions before routine use.

First-use check

Before first use, inspect the quartz faces and closure seating area for dust, chips or residue. Rinse with a suitable cleaning liquid, place the cell in the holder, and run a blank to confirm that the beam passes cleanly through the intended sample region without clipping or visible bubbles.

Fit and optical alignment

The stated external dimensions are 12.5 × 12.5 × 45 mm, with a 12.5 × 12.5 mm base. That helps you check holder fit and top clearance in the cuvette compartment, especially in compact instruments.

This is a Two-Way Light cell for straight-through transmission. Z Height is not specified for this SKU, so instruments with a fixed beam position should be checked for beam-center alignment rather than selected from outer dimensions alone. The 3 mm sample-region width should also be considered against your beam size.

Solvents and cleaning

This cuvette uses Standard 80 adhesive-bonded quartz construction. For this type, routine room-temperature aqueous samples and buffers are the usual selection direction, and organic samples or organic cleaning solvents should be avoided.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the optical faces gently with non-abrasive optical tissue. The exact chemical limits of the full wetted assembly are not established here, so choose cleaning and sample conditions with the complete cell and closure in mind.

Included with this option

Price is for 1 cuvette. A closure is included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We also coordinate custom JGS1 quartz cuvette enquiries when you need changes to dimensions, optical path length, sample volume, optical windows, Z Height, closures or fabrication details. If you need a modified version, send your drawing or holder information and quote part number C102SS17 via this contact page.
