(C104TE8) Quartz Micro Cuvette, 10 mm Path, 350 µL

Weight	30 g

SKU: C104TE8

Original price was: $475.00.Current price is: $428.00.

In Stock

C104TE8 is a JGS1 quartz micro cuvette for fluorescence measurements with a 10 mm optical path, Four-Way Light access and a 350 µL nominal capacity. Its 1 mm sample-region width suits methods that need a narrow defined filled region, and the closure is included. Sold as 1 cuvette.

In Stock

SKU: C104TE8 Categories: Cuvettes, Products, Quartz Fluorescence Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C104TE8 is a JGS1 quartz micro cuvette for fluorescence work where you need a 10 mm optical path in a compact format. This option combines Four-Way Light access with a 1 mm sample-region width and 350 µL nominal capacity, making it useful when your method is built around a narrow measured region rather than a broader chamber. It is sold as 1 cuvette, with closure included.

Path Length: 10 mm
Sample Volume (Nominal): 350 µL
Closure Type: Screw Cap

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	Fluorescence Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Four-Way Light
Optical Window Dimensions	1 mm
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	350 µL
Base Dimensions	12.5 × 12.5 mm
Material	Quartz
Material Grade	JGS1
Closure Type	Screw Cap
Closure Included	Yes
Fabrication Method	Molded 83
Detection Channel Width	1 mm

Choose this option

Choose C104TE8 when your method needs a narrow 1 mm sample region together with a standard 10 mm optical path. That combination helps when you want a clearly defined filled zone inside a micro cuvette body, while the 350 µL nominal capacity keeps this option in the smaller-volume end of the series. Four-Way Light access also makes it suitable for fluorescence layouts that use optical access from more than one side.

What makes this option different

10 mm optical path for methods specified around this path length.
1 mm sample-region width for a narrow defined measurement region.
350 µL nominal capacity in a micro cuvette format.
Four-Way Light layout for optical access from multiple sides of the cell.
Closure included with the single-cuvette sale unit.

Using this cell

Fill the cell so the illuminated region is fully covered during measurement, and keep bubbles or droplets away from the optical faces. With a narrow 1 mm sample region, stable orientation matters, especially when you compare blank and sample readings or repeat runs.

Fit the included closure gently and keep the contact surfaces clean. The stated 350 µL is the nominal capacity of the cell, not a minimum working volume, so your practical fill level should be based on beam coverage in your own instrument.

First-use check

Inspect the optical faces, body and closure contact area for chips, residue or handling marks.
Test the fit in your holder before preparing samples.
Run a blank and confirm that the filled region fully covers the illuminated area.

Fit and optical alignment

The confirmed base dimensions are 12.5 × 12.5 mm, which helps with holder seating at the base. Z Height is not established for this option, so do not assume beam-center alignment from base size alone if your instrument depends on a fixed beam height.

The stated 1 mm dimension describes the sample-region width. Use it to check whether your beam footprint and measurement geometry suit this narrow internal region.

Solvents and cleaning

This cuvette uses Molded 83 fabrication. This construction is commonly selected for methods that may involve organic solvents or temperature-controlled work, but suitability still depends on the full assembly and your actual chemical, concentration, temperature and contact time.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning. Clean the optical faces gently with non-abrasive optical tissue and use a cleaning routine that also suits the included closure.

Included with this option

1 quartz micro cuvette with screw cap.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz cuvettes for changes involving dimensions, optical path length, sample volume, optical windows or Z Height, closures and fabrication. Send a dimensioned drawing or labelled sketch together with holder details, sample conditions and target quantity. Prototype batches typically involve 2–4 cells; final specifications, price and production time are confirmed in quotation. Discuss your requirements and quote C104TE8.
