(C104CE16) Quartz Micro Cuvette, 10 mm / 5 mm (dual path) Path, 1.75 mL, Pack of 2

Weight	30 g

SKU: C104CE16

Original price was: $646.00.Current price is: $582.00.

In Stock

JGS1 quartz micro cuvette for fluorescence spectroscopy with a 10 mm primary path, 5 mm secondary path and Four-Way Light access. Its 1.75 mL nominal capacity and 5 mm stated sample-region width suit methods that need side optical access in a compact cell. Supplied as a pack of 2 quartz micro cuvettes, with a closure included.

In Stock

SKU: C104CE16 Categories: Cuvettes, Products, Quartz Fluorescence Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C104CE16 is a JGS1 quartz micro cuvette for fluorescence spectroscopy with a 10 mm primary path and a 5 mm secondary path in one compact body. Its Four-Way Light layout gives optical access from four sides, and the 1.75 mL nominal capacity supports routine small-volume handling while keeping the larger 10 mm transmission direction available. This sales option is supplied as a pack of 2 quartz micro cuvettes, with a closure included.

Path Length: 10 mm / 5 mm (dual path)
Sample Volume (Nominal): 1.75 mL
Closure Type: Lid

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	Fluorescence Spectroscopy
Pack Quantity	Pack of 2
Path Length	10 mm / 5 mm (dual path)
Light Transmission Configuration	Four-Way Light
Optical Window Dimensions	5 mm
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	1.75 mL
External Dimensions	12.5 × 12.5 × 45 mm
Uncapped Cell Dimensions	12.5 × 12.5 × 45 mm
External Dimensions Scope	Uncapped Cell
Material	Quartz
Material Grade	JGS1
Closure Type	Lid
Closure Included	Yes
Fabrication Method	Molded 83
Detection Channel Width	5 mm

Choose this option

Choose this cuvette when your method uses fluorescence geometry that benefits from four-side optical access and a defined 10 mm / 5 mm dual-path layout. The stated 5 mm sample-region width helps when planning beam placement around the sample area, and this pack-of-two sale unit suits labs that want the same specified cell in matched order quantity for routine use.

What makes this option different

10 mm / 5 mm dual-path geometry for methods built around two stated optical directions in one cell.
Four-Way Light configuration for optical access from four sides around the sample region.
1.75 mL nominal capacity in a compact micro cuvette format.
Pack of 2 cuvettes in this MQ sales option, with a closure included.

Using this cell

Fill the cell so the intended illuminated region is covered during measurement, then keep the same orientation for blank and sample runs. In fluorescence work, this is especially useful when side optical access is part of the method, because consistent seating keeps the same faces aligned with the instrument optics.

The 1.75 mL figure is the nominal capacity of the cell, not a minimum working volume. If your setup uses a fixed beam height or a small illuminated area, set the working fill level according to the actual holder and beam position rather than capacity alone.

First-use check

Inspect the optical faces, chamber and closure seating area before first use.
Place each empty cell in the holder to confirm body fit and top clearance.
Run a blank in the intended orientation and verify that the beam passes through the intended sample region.
Confirm that your fill level covers the illuminated area without bubbles or residue on the optical faces.

Fit and optical alignment

The stated external dimensions, 12.5 × 12.5 × 45 mm, apply to the uncapped cell body. Use those body dimensions to check holder fit and insertion clearance, and leave additional headroom because the installed height with the closure is not established here.

Z Height is not available for this SKU. If your fluorescence holder or accessory requires a defined beam-centre height, check that dimension in your own setup before routine use.

Solvents and cleaning

This cuvette uses Molded 83 fabrication. This MQ fabrication option is commonly selected for organic-solvent methods and applications involving temperature control, but the actual sample and cleaning routine should still be checked for the complete assembly you will use.

Do not use hydrofluoric acid with quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the exterior optical faces gently with non-abrasive optical tissue. Where your method involves aggressive chemicals, elevated temperature or long contact time, confirm suitability for the exact conditions before use.

Included with this option

Supplied as 2 micro cuvettes. A closure is included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz versions for changes to dimensions, optical path length, sample volume, optical windows, Z Height, closures and fabrication requirements. Send a drawing or labelled sketch together with holder details, application wavelength, sample conditions and target quantity for review. Discuss your requirements and mention part number C104CE16.
