Quartz 10mm Fluorescence Micro Cuvette, 350ul, Four-Way Light, Closure Included, 1pc/ea, C104CR6

Weight	30 g

SKU: C104CR6

C104CR6 Quartz 10mm Four-Way Light Fluorescence Cuvette 350 µl Closure Included

Original price was: $138.00.Current price is: $125.00.

In Stock

Quartz micro cuvette for fluorescence work with a 10 mm primary path, a 1 mm secondary path and Four-Way Light optical access in one compact cell. The 350 µL nominal capacity and open-top body support direct filling, and a lid is included. Supplied as 1 cuvette per price unit.

In Stock

SKU: C104CR6 Categories: Cuvettes, Products, Quartz Fluorescence Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C104CR6 is a quartz micro cuvette for fluorescence measurements that combines a 10 mm primary path, a 1 mm secondary path and Four-Way Light access in a compact body. Its 350 µL nominal capacity keeps the sample chamber small, while the open top lets you fill the cell directly and place the lid after loading. This option is sold as 1 cuvette per price unit.

Choose this option

Choose C104CR6 when your method needs side optical access together with a defined dual-path micro cell format. The 10 mm and 1 mm paths are built into the same cuvette, so you can plan around this specific geometry instead of a single-path cell. The open-top body is also practical when you want direct pipette access to the sample chamber during filling and inspection.

What makes this option different

Dual-path geometry: 10 mm primary path and 1 mm secondary path in one micro cuvette.
Four-Way Light layout: optical access on four sides for fluorescence measurement setups that use side illumination or collection geometry.
Open-top sample access: direct top filling instead of loading through a narrow port.
350 µL nominal capacity: a small chamber size for micro-volume preparation and handling.

Using this cell

Fill the chamber from the top opening and place the lid after loading if you want the sample covered between handling steps. Keep the optical faces clean and use a consistent cell orientation between blank and sample measurements.

The stated 350 µL is a nominal capacity, not a minimum working volume. If you plan to work below full fill, check in practice that the illuminated region remains fully covered and free of bubbles during the measurement.

First-use check

Inspect the optical faces and top opening for dust, chips or residue.
Test the bare cell in your holder before preparing sample.
Run a blank at your intended fill level to verify beam coverage.
Keep the same orientation once your measurement setup is established.

Fit and optical alignment

The stated 12.5 × 12.5 × 45 mm dimensions apply to the uncapped cell body. These body dimensions are useful for holder checks and compartment clearance, but they do not include any extra height or space taken by the lid.

Z Height is not established for this SKU. If your instrument has a fixed beam position or limited vertical adjustment, check beam alignment against the actual filled sample region before routine use.

Solvents and cleaning

This cuvette is described by the supplier as powder-fused. If your method requires a particular fabrication specification, confirm that requirement before ordering. Use cleaning and sample conditions suitable for quartz cells and for the complete wetted assembly.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning materials, and wipe the optical faces gently with non-abrasive optical tissue or another suitable laboratory wipe.

Included with this option

Supplied as 1 micro cuvette. A lid is included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

For related custom quartz cuvette requirements involving dimensions, path length, sample volume, optical windows, Z Height, closures or tolerances, please send your drawing or labelled sketch together with holder details and application conditions. Discuss your requirements and quote part number C104CR6.
