(C102CD14) Quartz Ultra-Micro Cuvette, 10 mm Path, 100 µL

Weight	30 g

SKU: C102CD14

Original price was: $108.00.Current price is: $98.00.

In Stock

C102CD14 is a JGS1 quartz ultra-micro cuvette for UV/Vis spectroscopy with a 10 mm optical path, Two-Way Light layout and 100 µL nominal capacity. Its open-top body and nominal 8.5 mm Z Height suit low-beam setups that need direct filling with more nominal volume than the smaller options in this series. Supplied as 1 cuvette, with a closure included.

In Stock

SKU: C102CD14 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C102CD14 is a JGS1 quartz ultra-micro cuvette for UV/Vis spectroscopy when you need a 10 mm optical path with a 100 µL nominal sample volume. This version combines a Two-Way Light layout with a nominal 8.5 mm Z Height, making it relevant for holders and instruments that place the beam lower from the cell base. The body is open at the top for direct filling, and the price is for 1 cuvette.

Path Length: 10 mm
Sample Volume (Nominal): 100 µL
Opening Configuration: Open Top (Cell Body)

Selection Specifications

Product Kind	Cuvette
Cell Type	Ultra-Micro Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Z Height	8.5 mm
Sample Volume (Nominal)	100 µL
External Dimensions	12.5 × 12.5 × 45 mm
Cell Body Dimensions	12.5 × 12.5 × 45 mm
External Dimensions Scope	Body Only
Material	Quartz
Material Grade	JGS1
MQ Grade	Standard 80
Closure Type	Open Top
Closure Included	Yes
Fabrication Method	Standard 80
Opening Configuration	Open Top (Cell Body)

Choose this option

Choose C102CD14 when your method needs a 10 mm transmission path and a small open-top cell, but with more nominal fill volume than the lower-capacity variants in the same family. The stated 8.5 mm Z Height is also important here, because path length alone does not tell you whether the beam will pass through the intended sample region in your holder.

What makes this option different

100 µL nominal capacity gives the largest nominal fill volume among these listed ultra-micro variants while keeping the same 10 mm path.
8.5 mm nominal Z Height supports setups built around a lower beam-centre position from the cell base.
Open-top access allows direct loading and visual checking of the sample region before measurement.
Two-Way Light layout is intended for straight-through UV/Vis transmission through the main optical faces.
Standard 80 adhesive-bonded construction is generally chosen for room-temperature water-based samples and buffers rather than organic-solvent methods.

Using this cell

Fill the open-top chamber carefully so the illuminated sample region is covered without bubbles. The 100 µL figure is a nominal capacity, not a minimum working volume, so set your practical fill level by beam coverage in your own instrument rather than by nominal capacity alone.

A closure is included and can help with handling after filling. This does not make the cell a pressure-rated or leak-tested assembly, because the body itself is still an open-top format.

First-use check

Inspect the optical faces and opening for dust, residue or handling marks.
Place the empty cell in the holder and confirm stable seating.
Run a blank and verify that the filled sample region fully covers the beam without bubbles.
Keep the same orientation for blank and sample measurements.

Fit and optical alignment

The stated body dimensions are 12.5 × 12.5 × 45 mm for the cell body only. Use that body-only size when checking holder seating and the available clearance above the cuvette position.

The nominal Z Height is 8.5 mm from the cell bottom to the optical centre. Compare this with your instrument beam height before ordering, especially if your holder was designed around a different optical centre. Matching the 10 mm path length alone is not enough to establish fit.

Solvents and cleaning

This cuvette uses Standard 80 adhesive-bonded quartz construction. It is commonly selected for room-temperature water-based samples and buffers. Avoid organic samples and organic cleaning solvents with this cell.

The exact chemical limits for the complete assembled wetted construction are not established here, so check compatibility before use if your sample or cleaning method is chemically demanding. Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the optical faces gently with non-abrasive materials.

Included with this option

Supplied as 1 ultra-micro cuvette. Closure included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz cuvettes for requirements involving dimensions, optical path length, sample volume, optical windows or Z Height, closures and fabrication details. If your holder, beam height or sample-handling method differs from this listed option, send a dimensioned drawing or labelled sketch together with the critical dimensions, sample conditions and target quantity.

Prototype batches typically involve 2–4 cells; feasibility, final specifications, price and production time are confirmed in the project quotation. You can contact us and quote part number C102CD14.
