(C202CA4) Quartz Large-Window Cuvette, 10 mm Path, 7 mL

Weight	100 g

SKU: C202CA4

Original price was: $72.00.Current price is: $65.00.

In Stock

C202CA4 is a JGS1 quartz large-window cuvette for UV/Vis work with a 10 mm optical path and 7 mL nominal capacity. The large optical face and included lid make it a practical choice for routine manual filling and upright bench use. Sold as 1 cuvette per price unit.

In Stock

SKU: C202CA4 Categories: Cuvettes, Products, Quartz Large Window Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C202CA4 is a JGS1 quartz large-window cuvette for UV/Vis spectroscopy with a 10 mm optical path and 7 mL nominal capacity. It suits methods that use a standard 10 mm path but need a roomier sample chamber and a broader optical face than a narrow routine cell. An included lid and compact body format support straightforward bench handling for single-cell measurements.

Path Length: 10 mm
Sample Volume (Nominal): 7 mL
Closure Type: Lid

Selection Specifications

Product Kind	Cuvette
Cell Type	Large-Window Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	7 mL
External Dimensions	22.5 × 12.5 × 45 mm
Cell Body Dimensions	22.5 × 12.5 × 45 mm
External Dimensions Scope	Body Only
Material	Quartz
Material Grade	JGS1
Closure Type	Lid
Closure Included	Yes

Choose this option

Choose C202CA4 when you want a standard 10 mm UV/Vis path in a large-window body that is easier to fill and inspect from the top during routine manual work. Its 7 mL nominal capacity gives you a practical chamber size for everyday loading and rinsing, while the included lid helps keep the cell set up for upright use on the bench or in a suitable holder.

What makes this option different

Large-window body with a 10 mm path: keeps the familiar UV/Vis path length while giving a broader optical face for beam access through the cell body.
7 mL nominal capacity: the chamber is sized for a fuller routine fill than micro-volume cells, which can make manual pipetting, rinsing and visual liquid-level checks more straightforward. This nominal volume is not a minimum working volume.
Fused integrated construction: the source describes this body as an integrated fused style rather than a separate assembled insert, which is useful when you want one complete cell body for routine filling, emptying and rinse-through handling.
Body dimensions of 22.5 × 12.5 × 45 mm: give you a clear starting point for holder and compartment checks, with the dimensions applying to the body only.
Lid included: supplied as a lidded single cuvette for upright use, with 1 cuvette per listed price unit.

Using this cell

Fill the cell from the top so the liquid fully covers the beam area used by your instrument, then remove visible bubbles before measurement. For routine UV/Vis work, keep the same orientation for blank and sample runs and handle the cuvette by non-optical surfaces where possible.

The 7 mL nominal capacity helps indicate the chamber size for ordinary filling and rinse cycles, but it should not be treated as a minimum required sample volume. The lid is useful for covered upright handling, but it is not a pressure rating or a seal-performance claim.

First-use check

Inspect the optical faces and lid on arrival, rinse the cell with a suitable liquid for your method, and run a blank before routine use. Check that the cell seats consistently in your holder and that your normal fill level covers the beam area used in measurement.

Fit and optical alignment

The listed 22.5 × 12.5 × 45 mm dimensions apply to the body only, excluding the lid. Allow extra clearance above the cell when checking compartment height or holder access.

Z Height is not listed for this SKU. If your instrument depends on a defined beam-center height, confirm that separately before ordering. The 10 mm path length alone does not establish beam-height compatibility.

Solvents and cleaning

This SKU is described in the source as fused integrated construction. For general background on cuvette construction approaches, see the Cuvette Fabrication Glossary.

Specific chemical limits for this exact SKU are not established here. Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the exterior optical faces gently with non-abrasive optical tissue.

Included with this option

1 cuvette per listed price unit. Closure included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz production for requirements involving dimensions, optical path length, sample volume, optical windows or Z Height, closures and connections, fabrication and tolerances. Send a dimensioned drawing or labelled sketch and identify the dimensions and tolerances that are critical to your application. Prototype batches typically involve 2–4 cells; the final quantity, feasibility, specifications, price and production time are confirmed in the project quotation. Modified designs and prototype batches are quoted separately from the listed SKU. Discuss your requirements and quote part number C202CA4.
