(C032CR8) Quartz Large-Window Cuvette, 3 mm Path

Weight	30 g

SKU: C032CR8

Original price was: $123.00.Current price is: $111.00.

In Stock

C032CR8 is a JGS1 quartz large-window cuvette for UV/Vis spectroscopy with a 3 mm optical path and an open-top body. It suits methods that need this shorter stated path in a large-window quartz cell with direct filling access. Sold as 1 cuvette per listed price unit.

In Stock

SKU: C032CR8 Categories: Cuvettes, Products, Quartz Large Window Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C032CR8 is a JGS1 quartz large-window cuvette for UV/Vis spectroscopy with a 3 mm optical path. Its open-top body gives direct access for filling, rinsing and visual checking, making it a practical choice when you want a short stated path in a full cuvette body rather than a flow-through or demountable format. This option is sold as one cuvette per listed price unit.

Path Length: 3 mm
Cell Type: Large-Window Cuvette
Opening Configuration: Open Top (Cell Body)

Selection Specifications

Product Kind	Cuvette
Cell Type	Large-Window Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	3 mm
Light Transmission Configuration	Two-Way Light
Material	Quartz
Material Grade	JGS1
Opening Configuration	Open Top (Cell Body)

Choose this option

Choose C032CR8 when your method calls for a 3 mm optical path and you want a quartz cuvette with direct top access. The large-window body format and open sample entry make it suitable for routine bench loading, blanking and cleaning in UV/Vis work where this path length is the main requirement.

What makes this option different

3 mm optical path for methods that require this shorter stated path length.
Large-window cuvette body for broad optical faces in a full cell format.
Open-top construction for direct filling and easy rinsing access.
JGS1 quartz for UV/Vis use rather than a visible-light-only glass cell.

Using this cell

Fill from the top and make sure the liquid level fully covers the instrument beam during measurement. Remove bubbles before reading, and keep the same orientation for blank and sample so the optical faces and sample presentation remain consistent.

Handle the cuvette by the non-optical outer surfaces. If you are working with low fill levels or a narrow beam geometry, check the practical fill height in your own setup because a minimum working volume is not listed here.

First-use check

Inspect the optical faces for residue, fingerprints, chips or scratches.
Rinse with a suitable liquid for your method and test with a blank.
Confirm that the cuvette seats securely in your holder and that the beam passes through the intended window area without clipping.

Fit and optical alignment

This is an open-top large-window cuvette body, so holder clearance and beam position matter as much as the stated path length. External body dimensions and Z Height are not listed here, so outside fit and beam-center alignment should be checked in the actual holder when your setup has tight mechanical or optical constraints.

If you need a fit review, send the holder model or a drawing with the available clearance and beam position.

Solvents and cleaning

Quartz is used here for UV/Vis work, but the exact chemical limits for this assembled SKU are not listed here. If your samples or cleaning routine involve demanding chemicals, check the exact liquid, concentration, temperature and contact time before ordering.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning. Clean the optical faces gently and dry with non-abrasive optical tissue. For background on MQ cuvette construction, see Cuvette Fabrication Glossary.

Included with this option

One C032CR8 cuvette. An included closure or other accessories are not established for this option.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We can review custom JGS1 quartz versions related to dimensions, path length, windows, Z Height, closures or fabrication requirements. Send a dimensioned drawing or labelled sketch, plus your instrument or holder details, application wavelength and sample conditions. Discuss your requirements and mention part number C032CR8.
