(C052CR6) Quartz Large-Window Cuvette, 5 mm Path

Weight	30 g

SKU: C052CR6

Original price was: $109.00.Current price is: $99.00.

In Stock

C052CR6 is a JGS1 quartz large-window cuvette for UV/Vis spectroscopy with a 5 mm optical path and an open-top body. It suits methods that need this shorter path length together with direct top filling and easy access for rinsing or sample inspection. Sold as 1 cuvette per price unit.

In Stock

SKU: C052CR6 Categories: Cuvettes, Products, Quartz Large Window Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C052CR6 is a JGS1 quartz large-window cuvette for UV/Vis spectroscopy with a 5 mm optical path. The open-top body gives direct access to the sample area, so it is easy to fill, rinse and visually check before measurement. This is a useful choice when your method calls for a 5 mm path in a full-size quartz cell rather than a closed or connected format.

Path Length: 5 mm
Cell Type: Large-Window Cuvette
Opening Configuration: Open Top (Cell Body)

Selection Specifications

Product Kind	Cuvette
Cell Type	Large-Window Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	5 mm
Light Transmission Configuration	Two-Way Light
Material	Quartz
Material Grade	JGS1
Opening Configuration	Open Top (Cell Body)

Choose this option

Choose C052CR6 when the key requirement is a 5 mm optical path with straightforward top access. The large-window body is practical for routine bench handling, while the open cell format keeps loading and cleaning simple for samples that are introduced manually rather than through tubing or a sealed cap arrangement.

What makes this option different

5 mm optical path: suited to UV/Vis methods set up for this stated path length.
Large-window cuvette body: gives a broad optical face in a full cell format.
Open-top access: supports direct filling, rinsing and sample inspection from above.
JGS1 quartz construction: specified for UV/Vis spectroscopy.

Using this cell

Fill the cuvette from the top and make sure the liquid level fully covers the beam during measurement. Remove visible bubbles before taking a reading, and keep the same orientation for blank and sample runs.

Handle the cell by the outer non-optical surfaces where possible. The open-top format is convenient for manual loading, but it also means your own fill level and beam position matter, especially in methods using smaller sample volumes.

First-use check

Inspect the optical faces on arrival, rinse the cell with a suitable liquid for your method, and run a blank before routine use. Confirm that the cuvette sits securely in the holder and that the filled sample covers the actual beam area in your instrument.

Fit and optical alignment

The stated selection point for this SKU is the 5 mm optical path. If your instrument or holder also depends on a specific body envelope or a defined beam center height, check those points before ordering, because external dimensions and Z Height are not established here.

For holder-limited setups, send the holder model or a drawing with available space and beam position. That is especially helpful when you need to confirm whether this large-window body format fits your instrument compartment.

Solvents and cleaning

This cuvette is made from quartz for UV/Vis use, but specific chemical limits for this exact assembled SKU are not listed here. If your samples or cleaning routine involve aggressive chemicals, please check suitability before ordering.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the optical faces gently with non-abrasive optical tissue. For general background on cuvette construction, see Cuvette Fabrication Glossary.

Included with this option

One C052CR6 cuvette. An included closure or other accessories are not established for this option.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We can review custom JGS1 quartz versions related to dimensions, optical path length, windows, Z Height, closures or fabrication requirements. Send a dimensioned drawing or labelled sketch, together with your instrument or holder details, application wavelength and sample conditions. Prototype batches typically involve 2–4 cells; feasibility, final specifications, price and production time are confirmed in the quotation. Discuss your requirements and mention part number C052CR6.
