(C405CR) Quartz Fluorescence Cuvette, 40 mm / 20 mm (dual path) Path, 23.6 mL

Weight	100 g

SKU: C405CR

Original price was: $237.00.Current price is: $214.00.

In Stock

C405CR is a JGS1 quartz fluorescence cuvette with a 40 mm / 20 mm dual optical path, Five-Way Light geometry and 23.6 mL nominal capacity. The open-top body gives direct access to the chamber, while the five-way light layout adds one more optical face than the usual four-side configuration. Sold as 1 cuvette per listed price unit.

In Stock

SKU: C405CR Categories: Cuvettes, Products, Quartz Custom Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C405CR is a JGS1 quartz fluorescence cuvette for fluorescence spectroscopy with a 40 mm / 20 mm dual optical path, 23.6 mL nominal capacity and a Five-Way Light layout. It combines a large open rectangular chamber with an additional light-transmitting face, which is useful when your setup needs more optical access than a four-side body provides.

The open top keeps filling, rinsing and visual sample checks simple, especially when you want direct access to the full chamber instead of working through a closure. The uncapped outer dimensions are 46 × 26 × 40 mm, so fit should be checked as an open cell body.

Path Length: 40 mm / 20 mm (dual path)
Sample Volume (Nominal): 23.6 mL
Opening Configuration: Open Top (Cell Body)

Selection Specifications

Product Kind	Cuvette
Cell Type	Fluorescence Cuvette
Measurement Mode	Fluorescence Spectroscopy
Path Length	40 mm / 20 mm (dual path)
Light Transmission Configuration	Five-Way Light
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	23.6 mL
External Dimensions	46 × 26 × 40 mm
Uncapped Cell Dimensions	46 × 26 × 40 mm
External Dimensions Scope	Uncapped Cell
Body Height	40 mm
Internal Dimensions	40 × 20 × 37 mm
Material	Quartz
Material Grade	JGS1
Opening Configuration	Open Top (Cell Body)

Choose this option

Choose C405CR when your method needs the stated 40 mm / 20 mm dual-path geometry together with Five-Way Light optical access. This option is particularly useful when the extra transmitting face matters to your measurement layout, while the open rectangular chamber supports direct loading and cleaning from above.

What makes this option different

40 mm / 20 mm dual optical path in one fluorescence cuvette body.
Five-Way Light layout with one additional transmitting face beyond a four-side configuration.
23.6 mL nominal capacity with a 40 × 20 × 37 mm internal chamber.
Open-top rectangular body for direct filling, rinsing and sample inspection.

Using this cell

Fill the chamber from the top opening and keep the selected optical faces clean in the beam region. When setting up the method, keep the same cuvette orientation for blank and sample measurements so the chosen optical direction remains consistent.

The stated 23.6 mL is a nominal capacity for the full cell, not a minimum working volume. If your method depends on low fill heights or a fixed beam-center position, check those conditions before use.

First-use check

Inspect the optical faces and edges under good light.
Rinse the chamber with a cleaning liquid suitable for your method.
Run a blank first and confirm the intended cell orientation in the holder.

Fit and optical alignment

The uncapped body dimensions are 46 × 26 × 40 mm, and the internal chamber measures 40 × 20 × 37 mm. Those figures help when checking holder clearance, top access and whether the chamber shape suits your filling routine.

This listing describes an open cell body, and the dimensions do not include any cap or closure. Five-Way Light identifies the optical access category, but it does not by itself establish fit with a particular fluorimeter or fixture. Z Height is not specified, so verify beam position against your holder before ordering.

Solvents and cleaning

This cuvette uses JGS1 quartz, and the supplier describes the construction as powder-fused quartz. For general fabrication background, see Compare fabrication methods.

Detailed chemical limits are not specified for this exact listed option. Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and wipe the optical faces gently with non-abrasive optical tissue.

Included with this option

1 cuvette per listed price unit. If you need a supplied closure or other accessory, contact us before ordering.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz projects for changes to dimensions, optical path length, sample volume, optical windows or Z Height, closures and connections, and tolerance requirements. Send a dimensioned drawing or labelled sketch together with your holder or instrument details. Discuss your requirements and quote part number C405CR.
