(MQAVC004) Custom Quartz Atomic Vapor Cell, Drawing-Based Configuration
Description
MQAVC004 is a custom quartz atomic vapor cell for atomic spectroscopy projects that need the cell to follow your drawing. This option combines a quartz body with a drawing-based configuration and a 20 mL nominal capacity, so you can order the cell around your apparatus layout instead of adapting the setup to a fixed standard shape. This sale is for one custom quartz atomic vapor cell.
- Sample Volume (Nominal)
- 20 mL
Selection Specifications
| Product Kind | Specialized Cell |
|---|---|
| Cell Type | Atomic Vapor Cell |
| Measurement Mode | Atomic Spectroscopy |
| Sample Volume (Nominal) | 20 mL |
| Material | Quartz |
| Pack Quantity | 1 Piece |
| Package Contents | 1 × Custom Quartz Atomic Vapor Cell |
Choose this option
Choose MQAVC004 when the physical layout of the atomic vapor cell needs to be defined for your experiment. A drawing-based cell is useful when the outer envelope, mounting space or beam position must be planned around a holder, heater, shield or other surrounding hardware. The listed 20 mL nominal capacity also helps when you need a larger sample region than a very small custom cell format, while keeping in mind that nominal capacity is not the same as minimum working fill.
What makes this option different
- Custom drawing-based configuration so the cell can be specified around your apparatus geometry rather than a fixed catalogue outline.
- Quartz cell body for atomic spectroscopy use.
- 20 mL nominal capacity to indicate the intended sample-region scale for this custom option.
- One-piece sale unit priced as 1 custom cell.
- Selection by drawing and quotation when fit, mounting space or beam position matters to the installation.
Structure and dimensions

Using this cell
Use this cell according to the agreed drawing and the operating method of your apparatus. When preparing the design, identify the intended optical path direction, the required sample-region layout and the mounting orientation so the finished cell matches the way you will place and align it in service.
The 20 mL figure is a nominal capacity for the cell, not a minimum working volume or a recommended fill level. If your method depends on a particular beam height, liquid or vapor coverage at the measurement position, include those requirements in the drawing review instead of relying on the nominal capacity alone.
First-use check
- Check the delivered cell against the agreed drawing or quotation.
- Verify physical fit in the holder or surrounding assembly before use.
- Confirm beam alignment at the intended measurement position with your normal setup procedure.
Fit and optical alignment
View the English selection reference.
Check the outer envelope, holder contact points and beam position against your own drawing before ordering. Z Height is not listed for this custom option, so beam-center fit should come from the drawing or from the dimensions of the cell you are replacing.
If the cell must fit closely into an existing holder or heated assembly, send a dimensioned drawing or a labelled sketch and mark the critical installation points. That is the most reliable way to keep body size, clearance and alignment consistent with your setup.

Solvents and cleaning
Select the sample and cleaning routine according to the actual chemicals and operating conditions in your application. If your process involves aggressive chemicals, organic solvents, elevated temperature or long contact time, include the chemical name, concentration, temperature and exposure time when discussing the design.
Do not use hydrofluoric acid with quartz. Avoid hot strong alkalis and abrasive cleaning. Clean optical faces gently with suitable non-abrasive optical tissue.
Included with this option
This sale covers the custom quartz atomic vapor cell configuration defined in the agreed quotation and drawing.
Availability and ordering
Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.
Discuss a custom version
Send the required drawing or labelled sketch, together with the critical outer dimensions, intended optical path direction, mounting orientation and any holder or fixture limits. If beam position or sample-region placement matters, include those points clearly on the drawing so the finished cell can be reviewed against the real installation. Send a product-selection enquiry with SKU MQAVC004.
Additional information
| Weight | 275 g |
|---|
