(MQQFC014) Quartz Rectangular Sample Cell, 10 mm Path, 4 mL, Open at Both Ends

Weight50 g
SKU: MQQFC014

$32.00

In Stock

JGS1 quartz rectangular sample cell with a 10 mm optical path, Two-Way Light geometry and a 4 mL nominal capacity. This cell body is open at both ends, giving direct access to the full sample channel for your own filling, retaining or end-treatment arrangement. Sold as 1 piece.

In Stock
Add to Wishlist
Add to Wishlist
Shipping and order support
  • Worldwide delivery to door service, hassle free shipping
  • Contact us for quotation of bulk purchase discount
  • Custom design. Send us graphic drawing for solution
  • POs for Academics. Pay after delivery.
  • Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

MQQFC014 is a JGS1 quartz rectangular sample cell with a 10 mm optical path in a compact 12.5 × 12.5 × 43 mm body. Its open-through design gives direct access from both ends, while the Two-Way Light layout supports transmission through two opposite optical sides. This format suits custom holders or assemblies where you need to define how the cell is filled, retained or finished at each end.

Path Length
10 mm
Sample Volume (Nominal)
4 mL
Opening Configuration
Open at Both Ends

Selection Specifications

Product KindSpecialized Cell
Cell TypeRectangular Sample Cell
Measurement ModeTransmission Spectroscopy
Path Length10 mm
Light Transmission ConfigurationTwo-Way Light
Wavelength Range — Lower Limit200 nm
Wavelength Range — Upper Limit2500 nm
Sample Volume (Nominal)4 mL
External Dimensions12.5 × 12.5 × 43 mm
Body Height43 mm
Base Dimensions12.5 × 12.5 mm
Internal Dimensions10 × 10 × 43 mm
MaterialQuartz
Material GradeJGS1
Opening ConfigurationOpen at Both Ends
Pack Quantity1 Piece

Choose this option

Choose MQQFC014 when you need a rectangular quartz cell body with a standard 10 mm transmission path and full end access. The 10 × 10 × 43 mm internal channel and 4 mL nominal capacity give a straightforward sample region for liquids or other materials that are introduced through the open ends, while the shorter external body helps when your fixture has limited vertical clearance.

View the English selection reference.

What makes this option different

  • Open at both ends means the sample channel is accessible from either side, so you can plan filling, retention and any end treatment around your own holder or fixture.
  • 10 mm optical path suits methods built around that transmission length without moving to a larger body style.
  • Two-Way Light geometry is arranged for a beam to pass through two opposite sides of the rectangular body, keeping the optical direction simple for transmission work.
  • Powder-fused construction is the supplier’s stated construction term for this cell, giving you a fused quartz body style to consider when choosing among fabrication types for your sample-handling and cleaning approach.
  • 10 × 10 × 43 mm internal channel with 4 mL nominal capacity provides a long, straight sample region that is easy to understand when planning fill level and beam coverage.
  • 12.5 × 12.5 × 43 mm exterior keeps the body compact for support design and holder-clearance checks.

Structure and dimensions

Product dimensions for checking holder clearance and sample access.
Product dimensions for checking holder clearance and sample access.Open image ↗

Using this cell

Use this cell as a sample cell body within a holder or assembly that controls how the open ends are retained during measurement. Because it is not supplied as a finished capped cuvette or connected flow cell, your end arrangement determines how you fill, position and secure the sample.

When filling, work with the cell in the same orientation you will use for measurement so the beam crosses the intended sample region consistently. Remove bubbles or liquid film from the transmitting faces before recording data.

First-use check

  1. Inspect the optical faces, end openings and body edges for chips, residue or handling marks.
  2. Install the cell in the intended holder and verify that it is supported without twisting or point loading.
  3. Run a blank or trial fill to check alignment, fill coverage and bubble behaviour in your actual setup.

Fit and optical alignment

Size the holder to the outside body dimensions, 12.5 × 12.5 × 43 mm, and support the cell on the outer surfaces rather than pressing on the optical faces. The internal dimensions describe the sample channel only and should not be used as the mounting size.

Z Height is not listed for this SKU. If your instrument or fixture requires a defined beam-center height, check that from the installed cell and actual beam path rather than from the overall body height alone.

English selection reference
Selection reference ↗

Solvents and cleaning

This cell is made from quartz and uses the supplier’s stated powder-fused construction. For practical use, choose sample and cleaning conditions for the complete assembly, including any seals, supports or end components you add.

Keep hydrofluoric acid away from quartz. Avoid hot strong alkalis and abrasive cleaning methods. Clean the optical faces gently with non-abrasive optical tissue and a cleaning approach suitable for your assembled setup. For fabrication background, see MQ Cuvette Fabrication Glossary.

Included with this option

1 rectangular sample cell, SKU MQQFC014. The listed price is for one piece.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We also coordinate custom JGS1 quartz versions for applications that need a different body size, path length, chamber geometry or end arrangement. Send a drawing or labelled sketch with the critical dimensions, beam position, sample conditions and target quantity if you need a modified version.

Send a product-selection enquiry with SKU MQQFC014 and your holder or application details.
