(MQQFC026) Quartz Rectangular Sample Cell, 3 mm Path, 756 µL, Open at Both Ends
Description
MQQFC026 combines a 3 mm optical path with a compact JGS1 quartz body and a 756 µL nominal chamber. The open-at-both-ends format is useful when you need a small rectangular sample region but want to provide the sealing, retention or liquid-handling method through your own fixture. This item is the cell body itself rather than a ready-connected assembly.
- Path Length
- 3 mm
- Sample Volume (Nominal)
- 756 µL
- Opening Configuration
- Open at Both Ends
Selection Specifications
| Product Kind | Specialized Cell |
|---|---|
| Cell Type | Rectangular Sample Cell |
| Measurement Mode | Transmission Spectroscopy |
| Path Length | 3 mm |
| Light Transmission Configuration | Two-Way Light |
| Wavelength Range — Lower Limit | 200 nm |
| Wavelength Range — Upper Limit | 2500 nm |
| Sample Volume (Nominal) | 756 µL |
| External Dimensions | 8 × 5 × 42 mm |
| Body Height | 42 mm |
| Base Dimensions | 8 × 5 mm |
| Internal Dimensions | 6 × 3 × 42 mm |
| Material | Quartz |
| Material Grade | JGS1 |
| Fabrication Method | Molded 83 |
| Opening Configuration | Open at Both Ends |
| Pack Quantity | 1 Piece |
Choose this option
Choose MQQFC026 when your method needs a 3 mm transmission path in a narrow rectangular format and space around the holder is limited. The slim outer envelope can help in compact fixtures, while the through-open chamber leaves the end treatment to your own mounting and sealing design.
What makes this option different
- 3 mm optical path: for methods that require this defined transmission distance.
- Compact 8 × 5 × 42 mm exterior: useful where holder clearance is tight and body size matters.
- Open at both ends: intended for a separate sealing or mounting arrangement rather than direct tubing connection out of the box.
- 756 µL nominal capacity: gives a small chamber volume within a 42 mm internal length.
Structure and dimensions

Using this cell
Install the cell so the beam crosses the 3 mm path in the intended orientation. Keep the same orientation during blank and sample measurements, especially if the holder contacts specific faces of the body.
Before routine use, establish how the open ends will be retained and sealed in your setup and confirm that filling and draining do not trap bubbles. The stated 756 µL is nominal chamber volume, not minimum working volume.
First-use check
- Inspect the optical faces, corners and end openings before mounting.
- Check holder fit and sample retention with a blank solution first.
- Verify that the final setup clears bubbles and exterior droplets before measurement.
Fit and optical alignment
Use the 8 × 5 × 42 mm outside dimensions to check the holder opening and support surfaces. The 6 × 3 × 42 mm inner dimensions describe the sample chamber and should not be used as the holder clearance size.
Z Height is not listed for this item, so instrument fit should not be assumed from the body size alone. If beam position is critical, match it through the holder design or send the drawing and required beam location for review.

Solvents and cleaning
Molded 83 is an MQ fabrication option often chosen for methods involving organic solvents or elevated-temperature use. Consider suitability for the complete assembly, including any sealing or support materials added around this open-ended body. For aggressive chemicals, heated operation or long contact times, send the liquid, concentration, temperature and contact time for review.
Keep hydrofluoric acid away from quartz. Avoid hot strong alkalis and abrasive cleaners. Clean the optical faces gently with non-abrasive optical tissue.
Included with this option
1 rectangular sample cell, SKU MQQFC026. The listed price is for one piece.
Availability and ordering
Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.
Discuss a custom version
We coordinate custom JGS1 quartz projects for changes to path length, body size, sample volume, optical windows, Z Height, interfaces, fabrication and tolerances. Send a drawing or labelled sketch with the critical dimensions, holder details and sample conditions.
Send a product-selection enquiry with SKU MQQFC026 if you need a different envelope, a defined end interface or a complete assembled cell.
Additional information
| Weight | 50 g |
|---|
