(C104CR31) Quartz Micro Cuvette, 10 mm Path, 1.75 mL

Weight	30 g

SKU: C104CR31

Original price was: $138.00.Current price is: $125.00.

In Stock

C104CR31 is a quartz micro cuvette with a 10 mm optical path, Four-Way Light access and 1.75 mL nominal capacity for fluorescence spectroscopy. Its open-top body is paired with a 5 mm sample-region channel, giving direct top loading with side optical access in a compact 12.5 × 12.5 × 45 mm uncapped body. Supplied as 1 cuvette per price unit.

In Stock

SKU: C104CR31 Categories: Cuvettes, Products, Quartz Fluorescence Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C104CR31 is a quartz micro cuvette for fluorescence spectroscopy with a 10 mm optical path and Four-Way Light configuration. This version combines an open-top body, a 1.75 mL nominal capacity and a 5 mm sample-region channel, so you can load directly from above while keeping side optical access around the sample region. It is supplied as 1 cuvette per price unit.

Path Length: 10 mm
Sample Volume (Nominal): 1.75 mL
Opening Configuration: Open Top (Cell Body)

Selection Specifications

Product Kind	Cuvette
Cell Type	Micro Cuvette
Measurement Mode	Fluorescence Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Four-Way Light
Wavelength Range — Lower Limit	200 nm
Wavelength Range — Upper Limit	2500 nm
Sample Volume (Nominal)	1.75 mL
External Dimensions	12.5 × 12.5 × 45 mm
Cell Body Dimensions	12.5 × 12.5 × 45 mm
Uncapped Cell Dimensions	12.5 × 12.5 × 45 mm
External Dimensions Scope	Uncapped Cell
Material	Quartz
Closure Type	Lid
Closure Included	Yes
Opening Configuration	Open Top (Cell Body)
Detection Channel Width	5 mm

Choose this option

Choose C104CR31 when you need a 10 mm fluorescence cuvette with direct top access and a larger nominal chamber within this compact body format. The open body helps when you want straightforward filling and visual access from above, while the 5 mm sample-region channel is the key geometry to check if your beam footprint or sample presentation needs this wider region.

What makes this option different

10 mm optical path in a quartz micro cuvette for fluorescence work.
Four-Way Light configuration for optical access from the sides of the sample region.
1.75 mL nominal capacity for methods that need this larger chamber size in the same compact body outline.
Open-top body for direct filling, inspection and cleaning access from above.
5 mm sample-region channel to check against your beam height and illuminated footprint.
Powder-fused construction as the supplier’s stated construction term for this option.
12.5 × 12.5 × 45 mm uncapped body for holder and clearance planning.

Using this cell

Fill the cell from the top opening and seat the closure carefully after loading. The open access makes it easier to add sample directly, inspect the liquid level and clean the chamber entrance without working through a narrow threaded or stoppered neck.

The 1.75 mL figure is the nominal capacity of the cell, not a minimum working volume. If you plan to use less than a full fill, make sure the illuminated region used by your instrument remains fully covered during measurement.

First-use check

Before first use, inspect the quartz faces, top opening and closure seating area for dust, chips or residue. Then run a blank in the intended holder position to confirm stable seating, suitable fill coverage and consistent orientation before measuring samples.

Fit and optical alignment

The listed 12.5 × 12.5 × 45 mm dimensions apply to the uncapped cell body. Use these dimensions to check holder fit and side clearance, then allow extra space above the cell for loading and for the fitted closure.

Z Height is not listed for this SKU, so outer body size alone should not be treated as proof of instrument fit. The 5 mm sample-region channel is also worth checking against your beam position and beam footprint, especially in fluorescence setups where the optical access geometry matters to your holder and detection arrangement.

Solvents and cleaning

This cuvette uses quartz and is described for fluorescence spectroscopy, but detailed chemical limits are not established here for this exact option. The supplier’s stated construction term is powder-fused construction, which is useful as a construction reference, but it should not be taken as a blanket solvent or temperature guarantee. General fabrication background is available here: https://machinedquartz.com/fabrication-method-of-cuvettes/.

Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and clean the optical faces gently with suitable non-abrasive optical tissue.

Included with this option

Supplied as 1 quartz micro cuvette with a lid included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We coordinate custom JGS1 quartz production for changes to dimensions, optical path length, sample volume, optical windows, Z Height, closures and related geometry. Send a dimensioned drawing or labelled sketch together with holder details, sample chemistry and quantity requirements. Discuss your requirements and quote part number C104CR31.
