Quartz 10mm Micro Fluorescence Cuvette, 0.7 ml, Standard 80, Four-Way Light, PTFE Cap, 1pc/ea, C104CS53

Not every fluorescence assay calls for the highest-grade fabrication. The C104CS53 gives budget-conscious laboratories a practical, four-window micro cuvette at a fraction of the cost of fused alternatives — without sacrificing the core geometry required for 90° fluorescence detection. With a 2 mm interior width carved by internal masking walls, the cell holds just 0.7 ml while maintaining a full 10 mm optical path. Standard 80 construction uses precision-applied optical adhesive to deliver transmittance above 80 % across 190–2 500 nm, making it well suited to aqueous-phase screening where solvent compatibility is not a concern.

In fluorescence spectroscopy, geometry is everything: the excitation beam enters one face, and the detector sits at 90° to capture emission through an adjacent face. The C104CS53 preserves that four-window layout in a micro-volume format, so you get the same angular relationships and path-length accuracy that higher-tier cuvettes provide — just at a lower price point. Standard 80’s precision-glued joints are fully compatible with aqueous buffers, dilute acids, and most biological media, covering the vast majority of routine fluorescence workflows. Reserve fused cuvettes for organic solvents or ultra-low-background work; for everything else, this cell keeps the cost per measurement low.

A full-size 10 mm fluorescence cuvette requires 3.5 ml of sample. The C104CS53 uses internal masking walls to shrink the active chamber to 2 mm wide, bringing the fill volume down to 0.7 ml — an 80 % savings. When you are working through dozens of aqueous samples per session, that reduction adds up quickly in both reagent cost and preparation time.

Usage Tips

• Use aqueous and mildly acidic or basic solutions only — avoid organic solvents that may soften the adhesive.
• Pipette slowly into the narrow 2 mm channel to minimise air-bubble entrapment.
• Clean promptly after use with deionised water; soak in dilute detergent if protein residue is present.
• Dry with filtered air or nitrogen rather than lab tissue to prevent lint on the optical faces.

Custom Orders

Need classroom packs, custom engraving, or bulk discounts for teaching labs? Contact our team for a tailored quote.

Disclaimer

Specifications are nominal and measured under standard laboratory conditions. Actual transmittance may vary slightly with wavelength and instrument baseline. This cuvette is designed for analytical spectroscopy and is not intended for medical-diagnostic or in-vivo use.
