(C102CD11) Quartz Ultra-Micro Cuvette, 10 mm Path, 10 µL

Weight	30 g

SKU: C102CD11

Original price was: $237.00.Current price is: $214.00.

In Stock

C102CD11 is a JGS1 quartz ultra-micro cuvette for UV/Vis spectroscopy with a 10 mm optical path, Two-Way Light layout and 10 µL nominal capacity. Its open-top body and nominal 15 mm Z Height suit low-volume filling while giving a defined beam-center height to check against your holder. Supplied as 1 cuvette, with a closure included.

In Stock

SKU: C102CD11 Categories: Cuvettes, Products, Quartz Micro Cuvettes Brand: MachinedQuartz

Shipping and order support

Worldwide delivery to door service, hassle free shipping
Contact us for quotation of bulk purchase discount
Custom design. Send us graphic drawing for solution
POs for Academics. Pay after delivery.
Availability and dispatch timing vary by item and quantity. Contact us to confirm timing for your order.

Description

C102CD11 is a JGS1 quartz ultra-micro cuvette for UV/Vis spectroscopy when you need a full 10 mm optical path in a very small-volume format. This version combines a 10 µL nominal capacity, Two-Way Light transmission and a nominal 15 mm Z Height, so it helps when both sample availability and beam position matter. The body is open at the top for direct filling, and the price is for 1 cuvette.

Path Length: 10 mm
Sample Volume (Nominal): 10 µL
Opening Configuration: Open Top (Cell Body)

Selection Specifications

Product Kind	Cuvette
Cell Type	Ultra-Micro Cuvette
Measurement Mode	UV/Vis Spectroscopy
Pack Quantity	1 Piece
Path Length	10 mm
Light Transmission Configuration	Two-Way Light
Z Height	15 mm
Sample Volume (Nominal)	10 µL
External Dimensions	12.5 × 12.5 × 45 mm
Cell Body Dimensions	12.5 × 12.5 × 45 mm
External Dimensions Scope	Body Only
Material	Quartz
Material Grade	JGS1
MQ Grade	Standard 80
Closure Type	Open Top
Closure Included	Yes
Fabrication Method	Standard 80
Opening Configuration	Open Top (Cell Body)

Choose this option

Choose C102CD11 when your method needs a 10 mm transmission path but only a very small nominal sample charge is available. The open-top body gives direct access to the sample chamber, while the stated 15 mm Z Height gives you a specific bottom-to-optical-centre value to compare with your instrument or holder before ordering.

What makes this option different

10 µL nominal capacity supports very small-volume UV/Vis work in a fixed 10 mm path format.
Open-top access lets you load the sample directly from above and inspect the filled region before measurement.
Two-Way Light layout is intended for straight-through transmission through the main optical faces.
15 mm nominal Z Height helps when your setup depends on a defined beam-centre height from the cell base.
Standard 80 adhesive-bonded construction is typically chosen for room-temperature water-based samples and routine buffer work rather than organic-solvent methods.

Using this cell

Fill the cell from the open top and add the sample carefully so the illuminated region is fully covered without trapping bubbles. With a 10 µL nominal capacity, handling technique matters: load slowly, check the liquid position before reading, and keep the same orientation for blank and sample.

A closure is included, which can help with handling after filling. The product is still an open-top cell body, so the included closure should not be treated as a pressure-rated or leak-tested seal.

First-use check

Inspect the optical faces and opening for dust, residue or handling marks.
Place the empty cell in the holder and confirm that it seats securely.
Fill with a blank and check that the illuminated region is fully covered without bubbles.
Use the same orientation for blank and sample runs.

Fit and optical alignment

The stated body dimensions are 12.5 × 12.5 × 45 mm for the cell body only. Use that body-only size to check holder seating and top clearance, especially if your instrument has limited access above the cuvette position.

The nominal Z Height is 15 mm from the cell bottom to the optical centre. Compare that value with your beam height before ordering. The 10 µL figure is a nominal capacity, not a minimum working volume, so your actual fill level still needs to cover the beam in your own setup.

Solvents and cleaning

This cuvette uses Standard 80 adhesive-bonded quartz construction. That construction is generally selected for room-temperature water-based samples and buffers. Avoid organic samples and organic cleaning solvents with this cell.

The exact chemical limits for the full assembled wetted construction are not established here, so check your sample and cleaning liquids before use if your method is chemically demanding. Do not use hydrofluoric acid on quartz. Avoid hot strong alkalis and abrasive cleaning, and clean the optical faces gently with non-abrasive materials.

Included with this option

1 cuvette. A closure is included.

Availability and ordering

Order this specification directly, or contact us to check current availability and dispatch timing. If temporarily unavailable, additional preparation or production time may be needed. For a required delivery date, contact us before checkout; preparation or production is separate from carrier transit and customs clearance.

Discuss a custom version

We can review custom JGS1 quartz versions related to dimensions, optical path length, sample volume, optical windows or Z Height, closures and fabrication requirements. Send your drawing or labelled sketch, instrument or holder details, sample conditions and required quantity. Discuss your requirements and quote part number C102CD11.
